Four Channels Cross Hole Ultrasonic Tester Ndt Testing Instruments ASTM D6760-02

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU960
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Cross Hole Ultrasonic System FOUR Channels Automatic Warranty: 1 Year
Standard: ASTM D6760-02 Master Control Unit: Buit-in A9 Industrial Control Motherboard
Operational Mode: Touch Screen One-time Section Mumber: 6
High Light:

Four Channels Cross Hole Ultrasonic Tester

,

Ndt Testing Instruments ASTM D6760-02

Product Description

Cross Hole Ultrasonic System Four Channels Automatic Concrete Testing Equipment



Standard:

ASTM D6760-02



Features:

※ newly upgraded wireless cloud transmission function;

※ stable performance and powerful function, it is the choice of users with diversified needs in engineering testing, teaching and scientific research;

※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;

※ semi reflective and semi transparent, high brightness, TFT color LCD screen;

※ full touch screen operation, simple and convenient, stable and reliable;

※ multi channel automatic acquisition, automatic recording of height and sound waveform;

※ the depth recording wheel adopts dust-proof and waterproof design;

※ large memory capacity and working time of more than 10 hours;

※ it can be directly connected to the digital rebound meter probe for ultrasonic rebound comprehensive strength measurement;

※ the U disk is used to transfer data and support software upgrading through the U disk;

※ the special analysis software has powerful functions, and data analysis and processing, report generation, and printing of reports can be easily completed;

※ the transducer spool is designed with a collector ring, and the signal cable can be retracted and retracted freely to prevent the cable from being twisted;

※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.



Description:

Rapid and continuous detection of foundation piles by ultrasonic transmission method; Rapid detection of continuous wall integrity; Structural concrete compressive strength test; Detection of crack depth of structural concrete; Detection of crack width of structural concrete; Bending resistance test of concrete pavement; Mechanical property testing of non-metallic materials such as rock mass and concrete.Concrete Testing Equipment



Specification:

Product Model BTU960
Master control unit Buit-in A9 industrial control motherboard
Display 10.1 inch, high brightness, TFT color LCD capacitive screen
Operational mode Touch screen
Storage mode Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk
Data transmission mode Wireless Cloud Transport(Options)
Acquisition mode Synchronous continuous rapid acquisition
One-time section mumber 6
Channel number 4(transmit and receive)
Trigger mode Signal triggering
Sampling period(μs) 0.05~409.6 Multistage Options
Acoustic time accuracy(μs) 0.05
Acoustic time range(μs) +1677700
Width measurement function

Range: 0~10mm

Accuracy: 0.01mm

Dynamic range(dB) 146
Bandwidth(kHz) 1~500
Receiving sensitivity(μV) ≤10
Emission voltage(V) 65, 250, 500 and 1000 gears adjustable
Communication UBS, Bluetooth, Wifi
Working hours(h) More than 8
Power supply mode

Built-in lithium battery

External 220V~ 16V AC/CD

Working environment Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%
Host size(mm) 300*200*55

Four Channels Cross Hole Ultrasonic Tester Ndt Testing Instruments ASTM D6760-02 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
