Waterproof Non Destructive Testing Equipment 6mm~50mm Rebar Detector In Concrete

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: RBL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Rebar Locator Warranty: 1 Year
Applicable Range Of Protective Layer Thickness(mm): ∅6mm~∅50mm Applicable Scope Of Diameter Estimation: ∅6mm~∅32mm
Maximum Error Of Diameter Indication: ±1 Specifications Section Grid: Graphic + Digital Display
High Light:

Waterproof Non Destructive Testing Equipment

,

50mm Rebar Detector In Concrete

Product Description

Rebar Locator Concrete Testing Equipment



Features:

1. Upgraded wireless cloud transmission function;

2. Adopt three anti-shell design, waterproof, dust-proof and shock-proof;

3. Large screen high resolution LCD screen, the interface has Chinese prompts, more intuitive display content;

4. Built-in large capacity memory card, storage capacity upgrade;

5. USB transmission simulates the host computer as a U disk and reads data as easily as a U disk.

6. Real-time display of protective layer thickness and steel signal image, minimum automatic locking;

7. Dual-range operation mode can effectively ensure the detection accuracy and maximum detection depth;

8. Automatic storage of test data, on-site statistical analysis results are provided immediately, which is convenient for guiding construction work;

9. Professional data analysis software, so that your post-processing data and report generation work can be easily completed.



Description:

The Rebar locator is a portable non-destructive testing instrument, which can be used for the detection of the construction quality of reinforced concrete structures. It can measure the position of steel bars on the concrete surface and detect the thickness of the protective layer of the steel bars and the diameter of the steel bars; ln addition, the position of magnets and
conductors in concrete structures can also be detected, such as cables and plumbing pipes inside walls. The detection before construction can effectively avoid damage to these facilities and reduce accidents.Concrete Testing Equipment



Specification:

Product model RBL
Applicable range of protective layer thickness(mm) ∅6mm~∅50mm
First range 6mm-90mm
Second range 6mm-200mm
Maximum allowable error of second range protective layer thickness ±1(mm) 6-80mm
±2(mm) 81-119mm
±4(mm) 120-200mm
Applicable scope of diameter estimation ∅6mm~∅32mm
Maximum error of diameter indication ±1 specifications
Section grid Graphic + digital display
Storage quantity 2000 components*1000 measuring points
Data transmission mode USB
Power supply mode Lithium battery
Host parameters Waterproof parameters:IP65
Screen size: 5 inches
Resolving power: 320x240
Volume: 195x140x45mm
Weight: 0.8kg
Powder supply Large capacity lithium battery for more than 12 hours
Working environment requirements

Temperature:-10℃~40℃

Humidty: <90%RH



Other requirements There is no corrosive gas in the air, No strong electromagnetic interface There should be no major shocks or shocks instruments to avoid direct sunlight
Packing Specification Material:Engineering plastics Volume: 420x140x335mm Weight: 5.5kg
