UNI 9189 Non Destructive Testing Equipment 2.207J Digital Concrete Test Hammer

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: HT-225D
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Digital Concrete Test Hammer Concrete Testing Equipment Standard: EN 12504 PART 2 ASTM C805 BS 1881:202 NF P18-417 DIN 1048 UNI 9189
Nominal Kinetic Energy: 2.207J Stiffness Of Spring: 785±30.0N/m
Pointer Length: 20.0+0.2mm Application: Concrete Testing Equipment
High Light:

UNI 9189 Non Destructive Testing Equipment

,

2.207J Digital Concrete Test Hammer

Product Description

Digital Concrete Test Hammer Concrete Testing Equipment

Standard​:
EN 12504 PART 2 ASTM C805 BS 1881:202 NF P18-417 DIN 1048 UNI 9189

Description:
·Built in nationalunified curve(JGJ/T23-2011)and multiple provincialmunicipal and district local strength measurement curves,supportreal-time measurement point strength estimation
and automatically calculate the measurement area strength and component estimated strength
after sampling
Drilling Fluids Testing Equipment
·Compliance standard: Industry Standard of the People's Republic of China rebound test
hammer(JJG817-2011)

·Small size,modular design,easy to replace the mechanical rebound test hammer
·Built in large capacity rechargeable lithium ion battery,long service life of the test hammer
·Built in large capacity memory can store 999 standard components,and a single component can set up 99 measuring areas and 159840 measuring point data at most

·Support break-point continuous test,and data collection is more convenient and humanized
·Support voice counting,measurement area conversion and component completion voice re- minder

·Support Bluetooth online,expand the use of mobile app connectionand make it more conve nient to upload data to the cloud with the cloud server
·Through data line connection and computer data processing softwarethe test data can be processed quickly and the test report can be issued
.Support system upgrade.According to user feedbackthe company wilupgrade the svstem


Specification:

Nominal kinetic energy2.207J
Stiffness of spring785±30.0N/m
Pointer length20.0+0.2mm
Pointer friction0.65+0.15N
Spherical radius of impact rodR25 ± 1.0mm
Working length of spring striking tension spring61.5±0.3mm
Tensile length of spring striking tension spring75.0±0.3 mm
Rated value of steel anvil80±2
Consistency of detection indicationTesting Ec<±1pment
Operatingtemperature-4℃~+40℃
Communication rate115200bps
Display2.08-inch 256x64(dot matrix) OLED display
Power supply1800mAh,3.7V lithium ion battery
Working hourscontinuous working≥10 hours
Test range10-60MPa
Concrete Testing Equipment
