DIN 1045 Portable Non Destructive Testing Equipment Concrete Rebar Locator Detector

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-ZD322
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Rebar Locator Detector Portable Warranty: 1 Year
Standard: BS 1881:204 DIN 1045 Diameter Measuring Range(mm): Ф6~Ф50
Working Temperature: -10℃~+42℃ Power Supply: Rechargeable Lithium Battery
High Light:

DIN 1045 Non Destructive Testing Equipment

,

DIN 1045 Rebar Locator Detector

Product Description

Rebar Locator Detector Portable Concrete Testing Equipment



Standard:

BS 1881:204 DIN 1045



Application Range:

(1). Testing the location, distribution, direction, and diameter of the rebar and the thickness of cover in concrete structure projects.

(2). Inspecting and accepting concrete structural construction quality.

(3). Evaluating the quality of construction.

(4). Establishing the location of rebar for drilling, cutting and coring operations.

(5). Testing the distribution and direction of electric cables, pipelines and metalwork inside walls and floors.

(6). Testing the quantity of rebar when evaluating and developing the old structure, such as installation of furniture and air-condition.



Features:

◆ The high resolution LCD display: 128 x 128 pixels;

◆ The intuitive operation and handheld ergonomic design with good durability;

◆ Accurately detect the location of the rebar;

◆ Help extend life of drill and avoid damage when drilling and coring;

◆ The multi coil structure design with high speed, high precision and high resolution;

◆ The built-in high capacity lithium battery, low power consumption, standby for no less than 20h.





Description:

  • ZD322 uses an electromagnetic induction method, which can detect the rebar location and cover thickness & diameter accurately, store, transfer and analyze the real time test data. The model ZD322 is the pinnacle of work with the modern simple design, incorporating the handy & durable features and sophisticated electronic technology.
  • ZD322 series rebar detector is mainly used to test the location, distribution, direction, the thickness of rebar and the diameter of cover in concrete structure such as walls, columns, beam-slabs etc. It can also detect the location of pipelines and metal embedded parts. The multiple coil structure design make it more accurate&responsive and higher resolution.Concrete Testing Equipment

Specification:

Items Technical Spec.
Diameter Measuring Range(mm) Ф6~Ф50
Measuring Range(mm)

Location Range: 1~120

First Range: 1~60

Second Range: 30~120

Thickness Measuring Accuracy(mm) 1~40 ±1
41~60 ±2
61~80 ±3
81~100 ±5
101~120 ±8
Rebar Location Accuracy 1~60 ±3
61-120 ±6
Diameter Measuring Modes Optional
JGJ Measurement Optional
Data Storage Optional
Off Time Automatic
Power Supply Rechargeable Lithium Battery
Working Temperature -10℃~+42℃
Size(mm) 170×78×38
Weight(kg) 0.28

DIN 1045 Portable Non Destructive Testing Equipment Concrete Rebar Locator Detector 0

DIN 1045 Portable Non Destructive Testing Equipment Concrete Rebar Locator Detector 1
