SGS 380VAC Concrete Testing Machine Cube Compression Testing Machine

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DYE
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 15 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: General Purpose Auto ASTM Compression Testing Machines Standard: EN, BS, ASTM, AASHTO
Power Supply: 220v ,AC 3 Phase 380V Compression Space(mm): 360\380
Maximum Test Force: 2000KN3000KN Piston Stroke(mm): 50\100\80
High Light:

380VAC Concrete Testing Machine

,

380VAC Cube Compression Testing Machine

,

SGS Cube Compression Testing Machine

Product Description

General Purpose Auto ASTM Compression Testing Machines Concrete Testing Equipment



Standards:

EN, BS, ASTM, AASHTO



Description:

Using hydraulic power source drive, electro-hydraulic servo control technology, computer data acquisition and processing, it is a high-precision material test equipment that can realize closed-loop control and automatic detection. It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system, and test instruments. The accuracy grade of the test machine is better than grade 1.



It can set the loading rate according to the corresponding international standards and meet the standard loading rate control index to carry out the compression test of cement, concrete and other materials under the rated test force. It has the function of dynamic display and timely control of load, time and test curve and the function of maintaining the maximum test force.



The testing machine is a main engine oil source split structure; It is applicable to the compression test of cement and concrete. Equipped with appropriate fixtures and measuring devices, it can meet the splitting tensile test and static elastic modulus test of concrete.



Test cubes up to 200 mm side and cylinders up to dia. 160 x 320 mm.  Concrete Testing Equipment



Features:

  • Simple and convenient operation
  • Stable and reliable, stable Afterburner, Pace Rate control between 1 kN to 25 kN
  • Load Accuracy Class 1
  • Tests automatically with closed loop control
  • The tests can be performed by controlling the machine either on control unit or on a computer with using Software
  • Load measurment with a pressure transducer
  • Mute servo motor
  • High precision spoke sensor
  • Hydraulic pump with dual stage for rapid approach
  • Four Columns frame with a single acting piston
  • Piston return at the end of test automatically
  • Maximum pressure valves to avoid machine overloading
  • Limit switch for piston stroke
  • Emergency stop button
  • Removable transparent front and rear safety doors
  • Software controlled maximum load value



Specification:

Model DYE-2000B DYE-2000A DYE-2000A1 DYE-3000A1
Maximum test force 2000KN 2000KN 2000KN 3000KN
Accuracy dass Level 1
Compression space(mm) 360 380
Piston stroke(mm) 50 100 80
size of upper comperssion plates(mm) 240x240 240x290 255x320
Size of lower platen(mm) 240x240 240x290 255x320
Extemal dimension(mm) 400x320x1100 460x370x1200 510x440x1300
dimension(contrd console)(mm)   1050x550x860
Power(kw) 1.1 1.5
Weight(kg) 1100 1200 1600

SGS 380VAC Concrete Testing Machine Cube Compression Testing Machine 0

SGS 380VAC Concrete Testing Machine Cube Compression Testing Machine 1



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
