Hebei Better United Import And Export Co., Ltd.

Masonary Concrete Testing Machine 2000KN 4000KN Compressive Strength Tester

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DYE
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 15 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: General Purpose Auto EN Compression Testing Machines Standard: EN, BS, ASTM, AASHTO
Power Supply: 220v ,AC 3 Phase 380V Maximum Test Force: 2000KN\3000KN\4000KN
Sensor Type: Oil Pressure Sensor Space Adjustment: Cushionblock
High Light:

Concrete Testing Machine 4000KN

,

4000KN Compressive Strength Tester

Product Description

General Purpose Auto EN Compression Testing Machines For Masonary Concrete Testing Equipment



Standards:

EN, BS, ASTM, AASHTO



Description:

Using hydraulic power source drive, electro-hydraulic servo control technology, computer data acquisition and processing, it is a high-precision material test equipment that can realize closed-loop control and automatic detection. It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system, and test instruments. The accuracy grade of the test machine is better than grade 1.



It can set the loading rate according to the corresponding international standards and meet the standard loading rate control index to carry out the compression test of cement, concrete and other materials under the rated test force. It has the function of dynamic display and timely control of load, time and test curve and the function of maintaining the maximum test force.



The testing machine is a main engine oil source split structure; It is applicable to the compression test of cement and concrete. Equipped with appropriate fixtures and measuring devices, it can meet the splitting tensile test and static elastic modulus test of concrete.



Test cubes up to 200 mm side and cylinders up to dia. 160 x 320 mm.  Concrete Testing Equipment



Features:

  • Simple and convenient operation
  • Stable and reliable, stable Afterburner, Pace Rate control between 1 kN to 25 kN
  • Load Accuracy Class 1
  • Tests automatically with closed loop control
  • The tests can be performed by controlling the machine either on control unit or on a computer with using Software
  • Load measurment with a pressure transducer
  • Mute servo motor
  • High precision spoke sensor
  • Hydraulic pump with dual stage for rapid approach
  • Four Columns frame with a single acting piston
  • Piston return at the end of test automatically
  • Maximum pressure valves to avoid machine overloading
  • Limit switch for piston stroke
  • Emergency stop button
  • Removable transparent front and rear safety doors
  • Software controlled maximum load value

Specification:

Model DYE-2000DF DYE-3000DF DYE-4000DF
Maximum test force 2000 3000 4000
Accuracy dass Level 1
Sensor type oil pressure sensor
Space adjustment Cushionblock
Compression space(mm) 360 400 500
Piston stroke(mm) 200 300
Size of upper platen(mm) Ф300 Ф320
Extemal dimension(mm) 640x560x1500 720x720x1610 760x760x1710
Extemal dimension of main engine(mm) 640x590x1400 700x600x1600
Weight(kg) 1200 1800 1900

Masonary Concrete Testing Machine 2000KN 4000KN Compressive Strength Tester 0

Masonary Concrete Testing Machine 2000KN 4000KN Compressive Strength Tester 1



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
