Hebei Better United Import And Export Co., Ltd.

2000kN 3000kN Horizontal Tensile Testing Machine Utm Tensile Testing Machine

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: WAL-600/1000/2000/3000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Universal Testing Equipment Standard export wooden box
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Horizontal Tensile Testing Machine Power Supply: 220v±10%,50/60Hz
Tensile Space(mm): 0-10000 Load Accuracy: ±1%
Load Range: 4%~100% Of Full Scale Application: Universal Testing Equipment
High Light:

3000kN Horizontal Tensile Testing Machine

,

2000kN Utm Tensile Testing Machine

Product Description

Horizontal Tensile Testing Machine Universal Testing Equipment



Description:

The horizontal tensile testing machine is mainly used to test the tensile mechanical properties of steel wire rope, anchor chain, steel strand, oil lifting rod, cable, hoisting belt, chain, power cable, power fittings, conveyor belt and other components; And compression test within a certain range. Application fields of horizontal tensile testing machine: construction industry, building materials industry, metallurgy industry, transportation industry, energy and resources industry, scientific research units, colleges and universities, quality inspection center, commodity inspection department, etc



This series machine is specially used for tensile, breaking strength, destructive test of steel wire rope, anchor chain, cable etc. This series uses a horizontal frame test opening to accommodate long specimens and high elongation demands. This machine adopts steel welded frame structure, and uses single-rod double-acting piston cylinder to provide loading force. cylindrical pin plug to mount specimen, and load cell to measure testing force. These test frames are powered by hydraulics for high strength testing and can be customized in length to meet a variety of application requirements. It can adjust the tensile space according to the length of specimen in test process.Universal Testing Equipment



Specification:

Model WAL-600 WAL-1000 WAL-2000 WAL-3000
Max.Load(kN) 600 1000 2000 3000
Load Range 4%~100% of Full Scale
Load Accuracy ±1%
Relative Error of Displacement ±1%
Stress Speed(Mpa/s) 1-45
Tensile Space(mm) 0-10000
Piston Stroke(mm) 500 or Customized
Method of Specimen Clamping Bolt way,Specially According to the Specimen that customer Provide
Control Mode Computer Controlled or Hand Valve Control
Effective Testing Space(mm) Width 750 or Customized
Fixed-way of Moving Beam Manual Bolt Fixed or Hydraulic Automatic Bolt
Power Supply 220v±10%,50/60Hz

2000kN 3000kN Horizontal Tensile Testing Machine Utm Tensile Testing Machine 0

2000kN 3000kN Horizontal Tensile Testing Machine Utm Tensile Testing Machine 1



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
