Hebei Better United Import And Export Co., Ltd.

Electromechanical Universal Testing Machine Computerized 10KN-300KN

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: WDW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Universal Testing Equipment Standard export wooden box
Delivery Time: 15 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Electronic Universal Testing Machine With Computer Standard: EN,ISO,ASTM,DIN
Power Supply: 220v ,AC 3 Phase 380V Effective Force Measuring Range: 2% ~ 100% F · S (no Gear In The Whole Process)
Force Value Accuracy: Better Than ± 1% \ ± 0.5% Of The Indicated Value Displacement Resolution (mm): 0.001
Displacement Accuracy: Better Than ± 1%\ ± 0.5% Of The Indicated Value Application: Universal Testing Equipment
High Light:

Electromechanical Universal Testing Machine 10KN

,

computerized universal testing machine 300KN

Product Description

Electronic Universal Testing Machine With Computer Universal Testing Equipment



Standards:

EN ISO 6892-1, EN ISO 15630-1, EN ISO 7500-1, EN 10002, ASTM A370, DIN



Description:

  • Adopt portal structure, double space form, aluminum alloy cover. The high-strength host frame is composed of high-precision ball screw and precision linear guide rail. All parts are processed by the machining center at one time to ensure the dimensional tolerance of the host and the accuracy of the whole machine.
  • It adopts domestic well-known brand electrical appliances, which are safe and reliable, and equipped with overload protection, overheat protection, leakage protection, photoelectric proximity switch and emergency stop button, so as to avoid losses caused by misoperation.
  • It adopts well-known brand measurement and control cards in the testing machine industry, brand computers, high-quality servo motors and servo controllers, high-precision load sensors and displacement sensors, so as to achieve accurate control, high response frequency and accurate indication. It can also detect various materials, such as metal, rubber, plastic, spring, wood, woven fabric, silk thread, etc.
  • Equipped with various fixtures, it is suitable for various tests and meets the tensile, compression, bending, shear, stripping and other tests of different materials.



Features:

  • Dual column electro mechanical floor standing model
  • High quality servo motor and servo controller
  • High precision load sensor and displacement sensor, class 1 and class 0.5 calibration
  • Overload protection limit sensor, non-contact extension limit sensor
  • Emergency power cut off button
  • Close loop. Control of load, displacement, extension, stress and strain
  • Remote control via software
  • Software updates and modification installation available via email or remote support
  • Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc
  • Different Testing Methods including cyclic, creep, relaxation, keeping etc
  • View data and graphs of previously ran tests
  • Determine and analyze data points such as yield point, breaking point, modulous etc
  • Test report printing options include direct to printer or excel file export
  • Test report data can be configured to show only necessary data and to exclude unused data
  • Raw data analysis for detailed test data
  • Exportable to excel and customizable to show user required dat
  • Universal Testing Equipment



Specification:

Model WDW-10B WDW-20B WDW-50B WDW-100B WDW-200B WDW-300B
Test force 10KN 20KN 50KN 100KN 200KN 300KN
Effective force measuring range 2% ~ 100% F · S (no gear in the whole process)
Force value accuracy Better than ± 1% ± 0.5% of the indicated value
Displacement resolution (mm) 0.001
Displacement accuracy Better than ± 1% ± 0.5% of the indicated value
Speed range 0.001mm/min ~ 500mm/min
stepless speed regulation
0.001mm/min ~ 300mm/min 0.001mm/min ~ 500mm/min 0.001mm/min ~ 300mm/min

Electromechanical Universal Testing Machine Computerized 10KN-300KN 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
