Electro Hydraulic Servo Universal Testing Machine 1000KN For Steel Strand Rebar

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: WAW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Application Standard export wooden box
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Servo Hydraulic Universal Testing Machine For Steel Strand And Steel Bar Power: Hydraulic
Standard: EN,ISO,ASTM,UNI Power Supply: 220v ,AC 3 Phase 380V
Motor: Taiwan Color: Customized
Relative Error Of Indication: ± 1% Deformation Measurement Range: 1%-100%F·S
Application: Universal Testing Equipment
High Light:

universal testing machine 1000kn

,

1000KN rebar testing machine

,

Servo Hydraulic Universal Testing Machine 1000KN

Product Description

Servo Hydraulic Universal Testing Machine For Steel Strand And Steel Bar Universal Testing Equipment



Standards:

EN ISO 6892-1, EN ISO 15630-1, EN ISO 7500-1, EN 10002, ASTM A370, UNI 7676



Description:

  • Using hydraulic power source drive, electro-hydraulic servo control technology, computer data acquisition and processing, it is a high-precision material test equipment that can realize closed-loop control and automatic detection. It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system, and test instruments. The accuracy grade of the test machine is better than grade 1.
  • The products with strong versatility can meet the various standard tests in the international regulations on metal tensile test, and can also realize the tensile, compression, bending, shear and other types of tests on different materials or products according to other standards. The tensile strength, yield strength, specified non proportional extension strength, elastic modulus and other performance indicators of the measured materials can be obtained, and the constant rate loading, constant rate deformation, constant rate displacement Constant rate strain and other closed-loop control can be used to verify the process qualification performance of materials or products.
  • The testing machine is a six column, double space structure. There is a tensile space between the upper beam and the lower beam, and a compressed space between the lower beam and the test bench. The test space is automatically adjusted by driving the lower beam up and down through the rotation of sprocket and lead screw. The upper and lower crossbeams are equipped with hydraulic control clamping jaws. The standard model is equipped with V-shaped and plane jaws for clamping cylindrical samples and flat samples for tensile tests, and the special jaws for steel strands are used for Φ 8~ Φ Tensile test of 18mm steel strand; The bottom end of the lower crossbeam of the standard model is equipped with an upper pressing plate, and the test bench is equipped with a lower pressing plate with a spherical structure, which can be directly used for compression test.
  • The design of the main machine of the testing machine considers the possibility of expanding and assembling other fixtures to complete more tests. For example, the bolt fixture can be used to stretch and maintain the load of bolts, the bending fixture can be used to conduct the bending test of round bars or plates, the shear fixture can be used to conduct the shear strength test of round bars, and the bending resistance, shear, splitting, elastic modulus instrument, etc. can be added in the compressed space to conduct the concrete and water mud sample block test. In addition, the product tests can be completed with steel balls, anchor chains, fasteners and other fixtures.



Features:

  • Six column providing superior axial and lateral stiffness and precision alignment
  • Hydraulic servo-controlled system regulating the load rate
  • Two different work spaces, the upper one for tension and the lower one for compression, bending and shearing, for a comfortable test execution
  • High precision load cell, class 1 and class 0.5 calibration
  • Digital displacement transducer for the best positioning and measuring accuracy
  • User friendly remote for Multifunctional control
  • Hydraulic jaws, for stronger clamping of the specimens
  • Overload protection limit sensor
  • Long piston stroke for the most convenient and easy adjustment and testing of different sample lengths
  • Easy calibration procedure
  • Remote control via software, text execution, data analysis available
  • Software updates and modification installation available via email or remote support
  • Diverse and robust configurations for test end options, graph options, PID values, crosshead movement speeds etc
  • Different Testing Methods including cyclic, creep, relaxation, keeping etc
  • View data and graphs of ran tests
  • Determine and analyze data points such as yield point, breaking point, modulous etc
  • Test report printing options include direct to printer or excel file export
  • Test report data can be configured to show only necessary data and to exclude unused data
  • Raw data analysis for detailed test data
  • Exportable to excel and customizable to show user required data
  • Universal Testing Equipment



Specification:

Item WAW-600 WAW-1000
Maximum test force 600KN 1000KN
Accuracy level Level 1
Relative error of indication ± 1%
Effective measurement range 1%-100% f · s (full range without grading)
Deformation measurement range 1%-100%F·S
Displacement measurement resolution 0.001mm
Lifting speed of middle beam 240 mm/min
Maximum spacing between compression surfaces 900 mm
Maximum stretching distance 900 mm
Effective distance between two vertical columns 375mm 455mm
Piston stroke 200 mm
Maximum speed of piston movement 120mm/min 100mm/min
Round specimen clamping diameter Φ13 mm -Φ40 mm Φ14 mm -Φ45
Clamping thickness of flat sample 0 mm -20 mm 0 mm -40 mm
Steel strand clamping diameter Φ8 mm –Φ18 mm
The maximum distance between the fulcrum of bending test 300 mm
Size of upper and lower pressing plates Φ200 mm Φ225 mm
Overall dimension of host 800 mm×620 mm×2450 mm 900 mm×700 mm×2700 mm
Size of oil source cabinet 800 mm×600 mm×1600 mm
Overall power 2.2kW (oil pump motor 1.5kw, lifting motor 0.4KW)
Weight of oil source cabinet 300 kg
Host weight about 2050 kg about 2800 kg
