ASTM D8044 200kN Universal Testing Machine Automatic Multipurpose Testers

Product Description

Automatic Universal Multipurpose Testers 200 kN Universal Testing Equipment

Standards:
ASTM D8044 AASHTO TP124 EN 12697-44 EN 12004-2

Description:

• The machine is composed by a sturdy base containing the transmission components and the hardware control instruments. The base holds two steel columns with ground hard chrome surfacing. The upper crosshead can be adjusted in height, to hold the accessories to perform the specific test. The lower mobile crosshead is operated by a recirculating ball screw and rotating lead, that through motor, assures the correct application of load and constant speed.
• This machine adopts advanced computer technology and high-precision sensor technology, with simple operation, accurate test data and stable performance. The instrument is equipped with overload protection. Instrument automatic test and automatic recording. The machine is mainly supported by two columns, with reasonable mechanical structure, so as to ensure the accuracy of the instrument. The design is simple and generous. After the pressure sensor is installed, it can be used to measure the unconfined compressive strength, CBR test, Marshall stability test of various binder stabilized soil specimens, and other tests requiring vertical load. It is equipped with double pressure sensors and double displacement sensors as standard.
• Electric load cell 200kN capacity, crosshead displacement device, upper with seat ball and lower compression platens.Universal Testing Equipment

Specification:


About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
