S-Type Load Cell Soil Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-STYLC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: S-Type Load Cell Scale Range: 50kg/100kg/150kg/200kg/300kg/500kg/1000kg/2000kg/5000kg/10000kg
Accuracy Class: 0.02 And 0.01 Comprehensive Error: ± 0.03%FS And 0.017%FS
Sensitivity: 2.0 ± 0.004mv/v Application: Soil Testing Equipment

Product Description

S-Type Load Cell Soil Testing Equipment



Description:

  • Using S-Type Load Cell, pull, pressure can be used.
  • High measuring accuracy, good stability, good output symmetry.
  • Force measuring system is widely used in belt scale, hopper scale, electro-mechanic scale, universal material testing machine, hook scales and various engineering devices. Soil Testing Equipment
  • Soil Testing Equipment

Features:

  • Made of alloy steel material, very durable
  • The surface is plated with Ni, which makes it well protected against water, dust and corrosion
  • S-beam structure design, practical and economic
  • Adopting to 4 cores shielded wire to transfer the signals
  • Strain gauge technology, analog output
  • Tension compression force measurement
  • Widely applied to various working environment

Specification:

Scale Range 50kg/100kg/150kg/200kg/300kg/500kg/1000kg/2000kg/5000kg/10000kg
Accuracy Class 0.02 And 0.01
Comprehensive Error ± 0.03%FS And 0.017%FS
Sensitivity 2.0 ± 0.004mv/v
Need To Change ±0.024%FS/30min And ±0.016%FS/30min
Zero Output 1.0%FS
Input Impedance 350 ±5Ω
Output Impedance 350 ±3Ω
Temperature Range -20 ~ +55℃
Safe Overload 120%
Ultimate Overload 150%



S-Type Load Cell Soil Testing Equipment 0
