Ultrasonic Planetary Ball Milling Machine 220V/50HZ 1 Year Warranty

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-UPBM
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Laboratory Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Ultrasonic Planetary Ball Mill Warranty: 1 Year
Material: Steel Power Supply: 220V/50HZ
Total Time Of Operation Setting: 1-9999 Application: Laboratory Testing Equipment
High Light:

Planetary Ball Milling Machine 220V

,

Planetary Ball Milling Machine 50HZ

Product Description

Ultrasonic Planetary Ball Mill Laboratory Testing Equipment



Product principle:

Four ball mill tanks are installed on a turntable. When the turntable rotates, the ball mill tank revolves around the main disk axis and reversely rotates around its own axis. The grinding balls and materials in the tank collide with each other during high-speed movement

Collision, shearing and friction to achieve the purpose of crushing, grinding, mixing and dispersing materials; At the same time, ultrasonic equipment (composed of ultrasonic generator and ultrasonic transducer) is configured, and the ultrasonic equipment is transferred to the grinding tank for passing

The conductive slip ring is realized, so that the inner wall of the grinding tank can continuously generate ultrasonic mechanical oscillation, and effectively solve the problems of the materials in the grinding tank of the traditional planetary mill after a certain ball milling time, such as bottom sinking, caking, wall sticking and agglomeration. At present

The equipment can only use various solid particles, suspensions and pastes with different particle sizes and materials under wet grinding conditions. The minimum particle size of the grinding products can reach nanometer level.



Features:

Compared with the XOM series of the same model, the structure of the equipment is more solid and the appearance is more atmospheric. It can realize vibration while grinding, and prevent the material from sinking, caking, sticking to the wall, agglomeration and other phenomena during grinding.



Description:

The ultrasonic planetary mill is a product developed based on the grinding principle of the traditional planetary mechanism. The equipment mainly uses dry mixing, with high requirements for fine grinding granularity. When using the traditional ball mill equipment, there will be sink and knot

Materials with block, wall sticking, agglomeration and other phenomena. Our ultrasonic planetary ball mill is small in size, full in function, high in efficiency and low in noise. It is an ideal equipment for scientific research institutions, colleges and universities, and enterprise laboratories to obtain research samples (four samples can be obtained at the same time in each experiment),. Equipped with a vacuum ball mill, the sample can be ground under vacuum.Laboratory Testing Equipment



Specification:

Model power supply rated power (kw) revolution rotation Total time of operation setting
PM-CSB-2 220V/50HZ 0.75 35-335 70-670 1-9999
PM-CSB-4 220V/50HZ 0.75 35-335 70-670 1-9999
PM-CSB-6 220V/50HZ 0.75 35-335 70-670 1-9999
PM-CSB-8 220V/50HZ 1.5 35-290 70-580 1-9999
PM-CSB-10 220V/50HZ 1.5 35-290 70-580 1-9999
PM-CSB-12 220V/50HZ 1.5 35-290 70-580 1-9999
PM-CSB-20 220V/50HZ 4 25-215 50-430 1-9999
PM-CSB-40 220V/50HZ 5.5 20-195 40-390 1-9999
PM-CSB-60 220V/50HZ 11 27-174 40-260 1-9999
PM-CSB-100 220V/50HZ 15 27-151 32-242 1-9999
