Galvanized Sheet 220v Forced Ventilation Oven Laboratory Drying Oven

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-LDO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Drying Oven Forced Ventilation OVEN Laboratory Ovens Standard: ASTM/EN/UNE/BS
Power Supply: 220v Studio Materials: Galvanized Sheet
Warranty: 1 Year Application: Soil Testing Equipment
High Light:

220v Forced Ventilation Oven

,

Galvanized Sheet Forced Ventilation Oven

,

220v Laboratory Drying Oven

Product Description

Drying Oven Forced ventilation OVEN Laboratory Ovens Soil Testing Equipment

Standards:
EN 932-5, 1097-5; ASTM C127, C136, D558, D559, D560, D698, D1557, D1559 BS 1377:1, 1924:11; UNE 103300

Description:

  1. The products are suitable for asphalt, soil, rock, concrete, aggregate or similar materials drying, melting, wax melting, sterilization and solidification of articles in industrial and mining enterprises, scientific research institutes, colleges and universities, medical and health laboratories.
  2. Temperature range is from ambient to 300°C.
  3. All models are fan circulated (forced convection), fitted with direct reading digital control unit and equipped with PID digital control system, isolated double wall construction, gasket single door and heating elements designed into air channels.
  4. Soil Testing Equipment


Features:

  1.  The shell is made of cold-rolled steel plate, and the surface is treated by spraying process, with novel and beautiful appearance
  2.  The inner tank is made of stainless steel plate or cold rolled plate after anti-corrosion treatment and processing
  3. A glass observation window is installed in the middle of the box door to observe the heated items in the studio at any time
  4. The door of the box is inlaid with rubber strips with good sealing to prevent heat loss
  5. Digital display of the temperature of the working room, easy to observe and read
  6. The temperature controller and platinum sensor with time proportion adjustment function are used as the temperature measurement system of the equipment, with high temperature control accuracy. Small measurement error
  7.  An exhaust valve is set on the upper side of the working room to discharge the moisture released by the heater out of the box at any time during operation
  8. Soil Testing Equipment


Specification:

Model Studio size Studio materials Power Overall dimension Weight
101-1A 350*450*450mm Galvanized sheet 2.0KW 710*550*710mm 45kg
101-2A 450*550*550mm Galvanized sheet 3.0KW 810*650*810mm 62kg
101-2B 450*550*550mm stainless steel 3.0KW 810*650*810mm 62kg
101-3A 500*600*750mm Galvanized sheet 4.0KW 860*700*1000mm 70kg
101-3B 500*600*750mm stainless steel 4.0KW 860*700*1000mm 70kg
101-4B 800*800*1000mm stainless steel 6.0KW 1130*990*1300mm 126kg
