ISO 3310-1 Laboratory Testing Equipment Dia 200mm Woven Wire Mesh Sieves

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-WWMS
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Laboratory Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Woven Wire Mesh Sieves Warranty: 1 Year
Standard: ISO 3310-1 EN 933-2 BS 410 UNE 7050 DIN 4187-1 UNI 2331 UNI 2333 ASTM E11 ISO 3310-2 NF X11-504 ISO 565 Material: Steel
Customization: Support For Custom Application: Laboratory Testing Equipment
High Light:

ISO 3310-1 Laboratory Testing Equipment

,

200mm Woven Wire Mesh Sieves

Product Description

Woven Wire Mesh Sieves Laboratory Testing Equipment



Standard:

ISO 3310-1 EN 933-2 BS 410 UNE 7050 DIN 4187-1 UNI 2331 UNI 2333 ASTM E11 ISO 3310-2 NF X11-504 ISO 565





Description:

  • High Quality Testing Sieves which are used in all types of sieve testing applications, from sampling and classification of soils, aggregates and other powdered and granular materials. Testing sieves are of the highest quality to ensure consistent fit, accurate specifications and durable construction.
  • Woven Wire Mesh Sieves are supplied in 200 mm and 300 mm frame diameters in various nominal aperture sizes suitable for several applications and standards.
  • Receiving Pans and Lids are available with 200 mm and 300 mm diameters.
  • There are three materials test sives includes stainless steel,polished chrome Iron sheet and brass.
  • Laboratory Testing Equipment



Specification:

Ø 200 mm Ø 300 mm
Nominal Aperture Size Nominal Aperture Size
125 mm 125 mm
100 mm (4”) 100 mm (4”)
90 mm (3 ½”) 90 mm (3 ½”)
80 mm 80 mm
75 mm (3”) 75 mm (3”)
63 mm (2 ½”) 63 mm (2 ½”)
56 mm 56 mm
53 mm (2.12”) 53 mm (2.12”)
50 mm (2”) 50 mm (2”)
45 mm (1 ¾”) 45 mm (1 ¾”)
40 mm 40 mm
37.5 mm (1-½”) 37.5 mm (1-½”)
31.5 mm (1 ¼”) 31.5 mm (1 ¼”)
28 mm 28 mm
26.5 mm (1.06”) 26.5 mm (1.06”)
25 mm (1”) 25 mm (1”)
22.4 mm (7/8”) 22.4 mm (7/8”)
20 mm 20 mm
19 mm (¾”) 19 mm (¾”)
16 mm (5/8”) 16 mm (5/8”)
14 mm 14 mm
13.2 mm (.530”) 13.2 mm (.530”)
12.5 mm (½”) 12.5 mm (½”)
11.2 mm (7/16”) 11.2 mm (7/16”)
10 mm 10 mm
9.5 mm (3/8”) 9.5 mm (3/8”)
8 mm (5/16”) 8 mm (5/16”)
6.7 mm (.265”) 6.7 mm (.265”)
6.3 mm (¼”) 6.3 mm (¼”)
5.6 mm (No. 3 ½) 5.6 mm (No. 3 ½)
5 mm 5 mm
4.75 mm (No.4) 4.75 mm (No.4)
4 mm (No.5) 4 mm (No.5)
3.35 mm (No. 6) 3.35 mm (No. 6)
3.15 mm 3.15 mm
2.8 mm (No. 7) 2.8 mm (No. 7)
2.5 mm 2.5 mm
2.36 mm (No.8) 2.36 mm (No.8)
2 mm (No.10) 2 mm (No.10)
1.7 mm (No. 12) 1.7 mm (No. 12)
1.6 mm 1.6 mm
1.4 mm (No. 14) 1.4 mm (No. 14)
1.25 mm 1.25 mm
1.18 mm (No.16) 1.18 mm (No.16)
1 mm (No. 18) 1 mm (No. 18)
850 μm (No. 20) 850 μm (No. 20)
800 μm 800 μm
710 μm (No. 25) 710 μm (No. 25)
630 μm 630 μm
600 μm (No. 30) 600 μm (No. 30)
500 μm (No. 35) 500 μm (No. 35)
425 μm (No. 40) 425 μm (No. 40)
400 μm 400 μm
355 μm (No. 45) 355 μm (No. 45)
315 μm 315 μm
300 μm (No. 50) 300 μm (No. 50)
250 μm (No. 60) 250 μm (No. 60)
212 μm (No. 70) 212 μm (No. 70)
200 μm 200 μm
180 μm (No. 80) 180 μm (No. 80)
160 μm 160 μm
150 μm (No. 100) 150 μm (No. 100)
125 μm (No. 120) 125 μm (No. 120)
106 μm (No. 140) 106 μm (No. 140)
100 μm 100 μm
90 μm (No. 170) 90 μm (No. 170)
80 μm 80 μm
75 μm (No. 200) 75 μm (No. 200)
63 μm (No. 230) 63 μm (No. 230)
53 μm (No. 270) 53 μm (No. 270)
50 μm 50 μm
45 μm (No. 325) 45 μm (No. 325)
40 μm 40 μm
38 μm (No. 400) 38 μm (No. 400)
