Hebei Better United Import And Export Co., Ltd.

Displacement Transducers Soil Testing Equipment Laboratory Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DTRS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Displacement Transducers Soil Testing Equipment Effective Stroke: Range+3mm
Mechanical Stroke(B): Range+8mm Case Length(A): Range+49mm
Recommended Temperature: 40℃~+80℃ Application: Soil Testing Equipment

Product Description

Displacement Transducers Soil Testing Equipment



Description:

  • It is a high precision linear position transducer with a long lasting conductive track.Especially for the places where the direction of length is limited and self-align is difficult.
  • It is widely used in injection mould, rubber machinery, wood-working machinery and hydraulic machinery.
  • Soil Testing Equipment

Features:

  • Stroke lengths available from 75mm to 1250mm
  • Slide type position sensor
  • High performance and reliability even under extreme temperature and vibration
  • High speed operation
  • Ruggedized construction and long life
  • Plug connection
  • Max protection class IP65
  • Soil Testing Equipment

Specification:

Type 50-110mm 125mm-175mm 200-700mm 750-1250mm
Independent linearity (±%FS) ±0.15% ±0.1% ±0.05% ±0.04%
Resistance (±10%) 5ΚΩ 10ΚΩ
Effective Stroke range+3mm
Mechanical stroke(B) range+8mm
Case Length(A) range+49mm
Resolution Infinite
Repeatability Precision 0.01mm
Max Speed 5 m/S
Recommended Temperature -40℃~+80℃
Protection level IP65
Mounting brackets with adjustable distance between centers
Useful electrical stroke(mm) 50 75 100 110 125 130 150 175 200 225 250 275 300 325 350 360 375 400 425 450 475 500 550 600 650 700 750 800 850 900 950 1000 1150 1250



Displacement Transducers Soil Testing Equipment Laboratory Testing Equipment 0
