Traffic Signs Handheld Color Spectrophotometer 400~700nm Wavelength

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BT4580 plus
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Traffic Sign Spectrophotometers Application: Asphalt Testing Equipment
Integrating Sphere Size: Φ48mm Wavelength Pitch: 10nm
Half Bandwidth: 10nm Reflectance Range: 0~200%
High Light:

Color Spectrophotometer 700nm

,

handheld Spectrophotometer 700nm

,

Traffic Signs Color Spectrophotometer

Product Description

Traffic Sign Spectrophotometers Asphalt Testing Equipment



Description:

The BT4580 plus high-precision color colorimeter adopts the 45/0 (45 degree circular illumination, 0 degree reception) geometric optical structure in accordance with CIE No.15, and adopts the concave grating spectral method, which can accurately measure the sample reflectivity and various chromaticity data. Equipment Φ 20mm large measuring caliber, used for accurate color measurement and quality control in traffic signs, plastic electronics, paint and ink, textile and clothing printing and dyeing, printing, ceramics and other industries. The instrument has a separate UV light source, which can be used for fluorescence sample measurement. The instrument is equipped with GB 2893 and GB/T 18833 standard colors. The polygonal rectangle tolerance can be manually customized, and the brightness factor and chromaticity coordinate measurement of traffic signs, markings and reflective film can be achieved with one button. For uneven samples or granular samples with stripes, the instrument has high accuracy and high stability.

Under the 45/0 geometric optical illumination condition recommended by CIE, the instrument can accurately measure the reflectance data of samples/fluorescent samples, and can accurately measure and express various color difference formulas and color indexes in various color spaces. With the help of this instrument, accurate color transmission can be easily realized, and it can also be used as a detection device for accurate color matching system. The instrument is also widely used in color difference quality control of various products. The instrument is equipped with high-end color management software, which can be used by connecting computers to achieve more function expansion.

Asphalt Testing Equipment



Features:

1. Perfect combination of beautiful appearance and structural design in line with human mechanics;

2.45/0 geometric optical structure, in accordance with CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7;

3. Combined LED light source with high life and low power consumption, including UV/excluding UV;

four Φ The diameter of 20mm is suitable for the test of larger samples or uneven samples;

5. Measure the sample spectrum, and the Lab data is accurate, which can be used for color matching and accurate color transfer;

6. High electronic hardware configuration: 3.5 inch TFT true color screen, capacitive touch screen, concave grating, 256 pixel dual array CMOS detector, etc;

7. USB/Bluetooth 4.0 dual communication mode, wider adaptability;

8. Super dirt-resistant and stable standard whiteboard;

9. Large-capacity storage space can store more than 30000 test data

10. Two standard observer angles, multiple light source modes, multiple surface color systems, and chromaticity indicators that meet various standards to meet the needs of various customers for color measurement;

11. PC software has powerful function expansion;

12. Built-in standard polygon tolerance setting and specific traffic landmark color gamut, especially suitable for traffic landmark brightness factor and chromaticity performance judgment.



Specification:

Model BT4580plus
Illumination/Observation system

45/0(45 ring-shaped illumination, vertical viewing);

Comply with CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7,GB 2893,GB/T 18833

Features

20mm aperture special design for traffic signs , It is used to measure the brightness factor and color coordinates of traffic

signs, markings and reflective films. It contains GB 2893 and GB/T 18833 standard colors. It can customize the rectangular

tolerance of polygons manually.

It is used for accurate analysis and transmission of laboratory color, also for Fluorescence sample color measurement .



Apply in paints, inks, textiles, garments, printing and dyeing, printing etc industries for color transfer and quality control.

Integrating Sphere Size Φ48mm
Light Source Combined LED Light, UV Light
Spectral separation device Concave Grating
Detector 256 Image Element Double Array CMOS Image Sensor
Wavelength Range 400~700nm
Wavelength Pitch 10nm
Half Bandwidth 10nm
Reflectance Range 0~200%
Measuring Aperture Φ20mm
Color Space CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB,βxy
Color Difference Formula ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE(Hunter)
Other Colorimetric Index

WI(ASTM E313,CIE/ISO,AATCC,Hunter),

YI(ASTM D1925,ASTM 313),

TI(ASTM E313,CIE/ISO),

MI (Metamerism Index),

Staining Fastness, Color Fastness, Color Strength, Opacity,Supporting Colorimetric Polygon Tolerance

Observer Angle 2°/10°
Illuminant D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
Display Data Spectrogram/Values, Chromaticity Values, Color Difference Values/Graph, Pass/Fail Result, Color Offset
Measurement Time About 1.5s
Repeatability

Spectral reflectance: Standard deviation within 0.1% (400 nm to 700 nm: within 0.2%)



Chromaticity value:within ΔE*ab 0.04 ( When a white calibration plate is measured 30 times at 5 second intervals after white

calibration)

Inter-instrument Error Within ΔE*ab 0.2 (Average for 12 BCRA Series II color tiles)
Measurement mode Single Measurement, Average Measurement(2-99)
Size(L*W*H) 184*77*105mm
Weight About 600g
Power source Li-ion battery. 5000 measurements within 8 hours
Illuminant Life Span 5 years, more than 3 million times measurements
Display 3.5-inch TFT color LCD, Capacitive Touch Screen
Interface USB, Bluetooth 4.0
Data memory Standard 1000 Pcs, Sample 30000 Pcs
Language Chinese,English
Working Environment Temperature: 0~40℃; Humidity: 0~85% (No Condensation);altitude: less than 2000 m
Storage Environment Temperature: -20~50℃; Humidity: 0~85% (No Condensation))
Standard Accessory

Power Adapter, USB Cable, Built-in li-ion battery, User Manual, software(download from the website)White and Black Calibration

Board, Protective Cover.

Optional Accessory Micro Printer, Powder Test Box, Universal test components, Locating Plate
Notes: The specifications are subject to change without notice.
