Automatic 50KN 30KN Marshall Stability Test Machine For Asphalt

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-AAMSCT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Advance Automatic Marshall Stability Compression Tester 50 KN Or 30KN Standard: EN 12697-34 ASTM D1559 ASTM D5581 AASHTO T245 NF P98-252-2
Maximum Load: 50kN. Measuring Range: ≤ 40kN.
Measurement Error: ≤± 0.1kn. Application: Asphalt Testing Equipment
High Light:

30KN Marshall Stability Test Machine

,

50KN Marshall Stability Test Machine

Product Description

Advance Automatic Marshall Stability Compression Tester 50 KN Or 30KN Asphalt Testing Equipment



Standard:

EN 12697-34 ASTM D1559 ASTM D5581 AASHTO T245 NF P98-252-2



Features:

1. The instrument is equipped with overload protection and falling over position protection. It has the functions of parameter setting, metering correction, automatic test control, automatic data collection, real-time clock, etc. the control device collects the test data for the stability and flow value of the test piece at the same time and automatically judges the peak value.

2. The instrument adopts large screen graphic LCD screen to directly display the test data and curve graph of stability value and flow value, test results and test time, and display the test effect intuitively Asphalt Testing Equipment

3. The test data and test time can be stored in the instrument, and can be called out and viewed at any time. The whole test is completed automatically and can be returned automatically.

4. The instrument also has the function of manually controlling the rise, fall and stop, which is convenient for users.

Note: 1 Ф 100mm specimen loading fixture is the standard configuration of this instrument.

2. Specimen loading fixture: Ф 101.6mm and Ф 152mm each.



Description:

It is applicable to determine the thermal stability and the ability to resist plastic deformation stability and flow value of asphalt mixture, and provide accurate basis for the composition and proportion design of asphalt mixture. It can accurately judge the damage point of asphalt mixture to carry out the mix proportion design of asphalt mixture or the construction quality inspection of asphalt pavement. Asphalt Testing Equipment



Specification:

Maximum load 50kN
Measuring range ≤ 40kN
Measurement error ≤± 0.1kn
Overload protection function automatic protection when the load value is greater than 49kN
Vertical deformation (flow value) measurement range: 0-20mm. Measurement error ≤± 0.05mm
Lifting speed of press (50 ± 5) mm / min
Communication interface RS232 serial communication port can communicate with computer
Working voltage AC220V ± 10%, 50Hz
Ambient temperature 0 ℃ ~ 60 ℃
Overall dimension 600mm × 380mm × 840mm (L × wide × High)
Motor power 550W
Weight (net weight) 98kg
Asphalt Testing Equipment

Automatic 50KN 30KN Marshall Stability Test Machine For Asphalt 0
