ASTM AASHTO Asphalt Testing Equipment 220v Automatic Marshall Compactor

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-AMC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden
Delivery Time: 6 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Automatic Marshall Compactor Power: Electronic
Standard: ASTM / AASHTO / EN / BS Power Supply: 220v
Application: Asphalt Test Color: Customized
High Light:

AASHTO Asphalt Testing Equipment

,

220v Automatic Marshall Compactor

Product Description

Automatic Marshall Compactor Asphalt Testing Equipment



Standards:

ASTM D6926, AASHTO T245, EN 12697-10, EN 12697-30, BS 958:107



Description:

The Automatic Marshall Compactor is designed to provide a stable and rigid mechanism to be used for preparation of bituminous specimens for Marshall Stability tests.



Marshall Compactor features a heavy-duty design, which stands up well to the constant jarring caused by the compaction process. The compactors are equipped with a hand operated mould fixing mechanism which locks the mould in place during compaction and reduces vibration of the mould. The conveniently positioned control panel comprises of start/stop button, emergency stop button and a direct reading counter used to set the required number of blows.The trip mechanism is structured so that the sliding hammer falls at the same height at every blow.



The apparatus stops automatically after the preset number of blows. The operator can keep track of the number of blows on an LCD display. All moving parts are quickly/easily accessible for maintenance.Asphalt Testing Equipment





Features:

  • Can realize automatic counting, automatic compaction, automatic shutdown.
  • With hanging hammer seat and manual handle, can easily lift the hammer.
  • Semi-automatic die pressing device, It is more convenient to pick and place the mold.
  • Integrated hammer head, won't fall off, won't breakor crack.
  • Small size Marshall test mode and large Marshall test mode can in common use.
  • For both 4" dia. and 6'' dia. specimens.
  • Suitable for laboratory work and field work.



Specification:

Item BTU-AMCL BTU-AMCH
Sliding Weight 4536 ± 9 gr 4536 ± 9 gr & 10210 ± 10 gr
Falling Height 457,2 ± 1,5 mm 457,2 ± 2,5 mm
Mould Dia. 4" (101.6 mm) 4" (101.6 mm) & 6" (152.4 mm)
Compact frequency 60 RPM
Compact time range 0-999 times
Power 220V / 380W
Dimension 540 x 540 x 1740 mm 670X570X1800mm
Weight 160KG 190KG

ASTM AASHTO  Asphalt Testing Equipment 220v Automatic Marshall Compactor 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
