Product Details:
|
|
| Place of Origin: | Made in China |
|---|---|
| Brand Name: | Btutest |
| Certification: | SGS, INTERTEK |
| Model Number: | BT808 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Asphalt Testing Equipment Standard export wooden box |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sets per month |
|
Detail Information |
|||
| Name: | Road Marking Spectrophotometers | Application: | Asphalt Testing Equipment |
|---|---|---|---|
| Measuring Aperture: | Φ8mm | Wavelength Range: | 400~700nm |
| Wavelength Pitch: | 10nm | Reflectance Range: | 0~200% |
| High Light: | Road Marking Portable Color Spectrophotometer,Portable Color Spectrophotometer SGS,Road Marking handheld Spectrophotometer |
||
Product Description
Road Marking Spectrophotometers Asphalt Testing Equipment
Description:
The BT808 special spectrophotometer for traffic road signs is equipped with D65/A/C/F2 and other light sources. The geometric light path structure is 45/0 (45 ° circular uniform illumination 0 ° reception). This instrument can conveniently test the brightness factor, chromaticity coordinates, CI E L * a * b and other chromaticity data of various reflective films; It is widely used in road traffic landmark testing, plastic electronics, paint and ink, textile and clothing printing and dyeing, printing paper, automobile, medical treatment, cosmetics, food and other industries, and in scientific research institutions and laboratories.
In GB 2893 Safety Color, GB/T 18833 Reflective Film for Road Traffic and other relevant standards, a color area (multiple chromaticity coordinate points) and brightness factor requirements are usually given. Under D65/A light source and 45/0 geometric conditions, it is determined whether the sample falls within the corresponding color area, so as to determine whether the sample meets the chromaticity requirements specified in the standard. Because the color area is polygonal, as shown in the figure below, it is impossible to complete the determination using ordinary spectrophotometer. NS808 colorimeter and SQCT software's traffic landmark measurement module can easily solve this problem. Asphalt Testing Equipment
Specification:
| Illuminating/Viewing Geometry |
45°/0 (45° ring-shaped illumination, vertical viewing angle), Conform to standard CIE No. 15, GB/T3978, GB2893, GB/T18833 |
| Measuring Aperture | Φ8mm |
| Integrating Sphere Diameter | Φ58mm |
| Repetitive Error |
Spectral Reflectance: Standard deviation within 0.1%(400~700nm: within 0.2%) Colorimetric Value: Standard deviation ΔE*ab≤0.04 (Measurement Conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration performed.) |
| Inter-Instruments Error | ΔE*ab≤0.2 (Average value of the measurement results of the 12 tint plates of BCRA series Ⅱ) |
| Wavelength Range | 400~700nm |
| Wavelength Pitch | 10nm |
| Reflectance Range | 0~200% |
| Color Space | CIE LAB, XYZ, Yxy, LCh, CIE LUV |
| Color Difference Formula | ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00 |
| Display Data | Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation |
| Other Chromaticity Data |
WI(ASTM E313, CIE/ISO, AATCC, Hunter), YI(ASTM D1925, ASTM 313), TI(ASTM E313, CIE/ISO), Metamerism Index (Mt), Color Strength, Color Stain, Color Fastness |
| Observer Angle | 2°/10° |
| Light Sources Type | D65, D50, A, C, D55, D75, F2, F6, F7, F8, F10, F11, F12 |
| Light Source Device | Combined LED Light |
| Light Source Life | 5 years, More than 1.6 million measurements |
| Sensor | Silicon Photoelectric Diode Array |
| Measuring Time | 1.5s |
| Data Storage | 1000 Standards, 15000 Samples |
| Data Port | USB&RS232 |
| Display Size | TFT 3.5" |
| Touch-Screen | Yes |
| Operating Temperature | 0~40℃(32~104℉) |
| Storage Temperature | -20~50℃(-4~122℉) |
| PC Software | SQCT |
| Weight | 600g |
| Dimension | 90*77*230mm |
| Battery | Large Capacity Li-ion Battery |
| Standard Accessory | Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM(containing color management software), Data Cable, White and Black Calibration Cavity, Protective Cover and Wrist Strap. |
| Optional Accessory | Universal Test Components, Micro Printer, Powder Test Box |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
