Multi Angle Portable Retroreflectometer Asphalt Testing Equipment Scratch Resistant

Product Description

Muti-Angle Portable Retroreflectometer Asphalt Testing Equipment

Description:

BT-MAR-932 multi-angle retro-reflection coefficient detector is a portable detection device used to measure the retro-reflection optical characteristics of various reflective safety materials, and is widely used for the on-site inspection and inspection of various road traffic reflective products, vehicle safety reflective products, safety production signs, reflective sheeting, etc.

Multi-angle sign retro-reflection coefficient detector is a new type of portable road traffic safety detection equipment, which adopts standard transfer indirect measurement method. The system adopts a new metal structure design with high precision, high stability and photoelectric integration. The system uses a 32-bit MCU main control module and embedded program control software based on Linux environment. It has a built-in large-capacity storage unit and a touch screen display loaded with soft keyboard input function. It has the use characteristics of no preheating, small measurement error, and instant use. Asphalt Testing Equipment

Main functional characteristics

1. Advanced optical measurement system

2. Scratch-resistant all-metal shell

3. Magnetic calibration method, more convenient

4. Support the measurement of retroreflection coefficient of up to 12 angles

5.4.3 inch high brightness LCD capacitive touch screen displays measurement data

6. It can preset parameters, display system information such as date, time, detection location, detection organization, license plate/road name, detection personnel, etc., and open English menu mode to foreign customers for convenient use. It has the function of automatically selecting detection color

7. Support real-time display of on-site temperature and humidity

8. Automatic calibration, zero setting and calibration of measurement standards

9. Input Chinese characters, English characters and characters with soft keyboard to store detection records, and can query in detail at any time

10. Intelligent standby management, turn off screen display system hibernation when there is no operation

11. Support multiple measurements to calculate the average value;

12. It supports the data storage of 16G SD card, and supports the data storage in the form of Excel table, which can be exported to the computer through the USB flash disk function;

13. Low illumination and high sensitivity photoelectric measuring device assembly

14. High-precision and high-stability analog data acquisition and A/D conversion circuit

15. Low-power, high-reliability main control unit and computing system

16. Support WIFI or Bluetooth data transmission function; (Optional)

17. Bluetooth printing function is supported, and detection data can be printed on site (optional);

18. Support GPS positioning function (optional);

Specification:
