Aluminum Shell Handheld Retroreflectometer For Traffic Signs Automatic Calibration

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Retroreflection Meter Handheld Retroreflectometer For Traffic Signs Measuring Value Range: 0-1999
Set The Incidence Angle: – 4 ° Set Observation Angle: 0.2 °
Measuring Diameter: > 30mm Application: Asphalt Testing Equipment
High Light:

Aluminum Shell Handheld Retroreflectometer

,

Aluminum Shell Sign Retroreflectometer

,

Handheld Retroreflectometer Automatic calibration

Product Description

Retroreflection Meter Handheld Retroreflectometer For Traffic Signs Asphalt Testing Equipment



Executive standard:

GB/T 18833-2012 Road Traffic Reflective Film

GB/T 26377-2010 Retroreflectometer

JJG 059-2004 Verification Regulation of Retroreflection Measuring Instrument



Description:

Sign retro-reflection measuring instrument is a new type of portable traffic safety detection equipment, which is used to measure the retro-reflection optical characteristics of various reflective safety signs, and is suitable for the on-site detection and inspection of traffic reflective products and vehicle safety reflective products. Asphalt Testing Equipment



Main functional features:

  • Imported aluminum shell
  • 4.3 "high brightness LCD capacitive touch screen
  • Large-capacity lithium battery, lasting for at least 2 days
  • Magnetic suction calibration/detection method, more convenient
  • Preset parameters, display date, time, power and other system information
  • New optimized precision algorithm
  • Automatic calibration, zero setting and calibration of measurement standards
  • Input Chinese characters and English by soft keyboard and handwriting
  • Store more than 99999 records, and can query the detection records in detail at any time
  • Support data storage in Excel form
  • Transfer the recorded data to the background terminal (PC) through USB interface and export it directly via USB flash disk
  • Photoelectric measuring assembly with long life, low illumination and high sensitivity
  • High-precision and high-stability analog data acquisition and A/D conversion circuit
  • Support multiple measurements to calculate the average value
  • Temperature and humidity real-time measurement display
  • Bluetooth printer (optional)
  • GPS positioning (optional)



Specification:

Measurement item retroreflection coefficient (unit: cd · lx-1 · m-2)
Measuring value range 0-1999
Set the incidence angle – 4 °
Set observation angle 0.2 °
Measuring diameter > 30mm
Accuracy ± 5%
Standby measurement time (intermittent measurement) ≈ 48h
Built-in power capacity 3400mA. h
Charging power supply DC5V
Operating ambient temperature 0-40 ℃
Ambient humidity < 80%
Operating weight 1860g
Overall volume: 220 * 246 * 82mm (L × H × W)

Aluminum Shell Handheld Retroreflectometer For Traffic Signs  Automatic Calibration 0

Aluminum Shell Handheld Retroreflectometer For Traffic Signs  Automatic Calibration 1


About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
