Hebei Better United Import And Export Co., Ltd.

LCD Display Environmental Testing Equipment Reflectorless Total Station DTM752R

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DTM822R
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Environmental Testing Equipment Export standard package
Delivery Time: 3 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Reflectorless Total Station DTM752R Warranty: 1 Year
Dimensions: 174×207×383mm Weight: 12 Kg
Lithium Battery: DC7.6V Application: Environmental Testing Equipment
High Light:

LCD Display Environmental Testing Equipment

,

Reflectorless Total Station DTM752R

Product Description

Reflectorless Total Station DTM752R Environmental Testing Equipment



Description:



Total stations are widely used in below fields, and are well received by worldwide surveyors and users.

Land surveying, Civil engineering, Topographic engineering Tunnel engineering, Water engineering.

Environmental Testing Equipment



Features:

  • Laser prism free ranging
  • Absolute coded angle measurement
  • Two axis electronic compensation
  • Simple and convenient operation
  • Large LCD display
  • Rich measurement procedures
  • Massive data storage

Specification:

DTM752R
Max distance (in good weather) Singles prism 3.0 Km
Three prisms 5.0Km
No-prism 400m 600m
Digital display Max: 99999999.9999 m Min.: 0.1 mm
Precision No-prism 5+3ppm, have-prism 2+2ppm
Unit m/ft for selection
Time for measuring Single fine measurement 2 sec. tracking 0.8 sec
Number of measurements 1~ 99
Meteorologic correction Automatic correction of input parameter
Atmospheric refraction and earth curvature correction Automatic correction of input parameter, K=0.14
Prism constant correction Automatic correction of input parameter
Angle measurement
Angle measurement method Absolute code
Grating disc dia. (horizontal, vertical) 79mm
Min. reading displayed 1″
Detection method

Horizontal circle: 2 sides

Vertical circle: 2 sides

Precision 2″
Telescope
Imaging Right reading
Barrel length 170mm
Objective lens effective aperture 48mm
Magnification 30×
Viewing angle 1°30′
Resolution 3.5″
Min. focus distance 1.5m
Automatic vertical compensator
System Single axis, double axis liquid electronic sensor compensation
Work range ±3′
Precision ±3 ″
Level
Plate level 20″/2mm, 30″/2mm
Circular level 8′/2mm
Optical plummet
Imaging Right reading
Magnification
Focusing range 0.5m~∝
Viewing angle
Display
Type Two sides, graphically
Data transmission
Interface RS-232C
Battery
Power supply Rechargeable Ni-MH battery, rechargeable lithium battery
Volt. Lithium battery: DC7.6V; Ni-MH battery: DC7.2V
Continuous operation time 8 hours
Size and weight
Size 174×207×383mm
Weight 6.8㎏
LCD Display Environmental Testing Equipment Reflectorless Total Station DTM752R 0


About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Environmental Testing Equipment

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Environmental Testing Equipment

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
