Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | BTU-DTM822R |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Environmental Testing Equipment Export standard package |
Delivery Time: | 3 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Windows CE Total Station DTM952R | Warranty: | 1 Year |
---|---|---|---|
Lithium Battery: | DC7.6V | Dimensions: | 174×207×383mm |
Weight: | 12 Kg | Application: | Environmental Testing Equipment |
High Light: | Environmental Testing Equipment DTM952R,DTM952R Windows CE Total Station,DC7.6V Windows CE Total Station |
Product Description
Windows CE Total Station DTM952R Environmental Testing Equipment
Description:
Total stations are widely used in below fields, and are well received by worldwide surveyors and users.
Land surveying, Civil engineering, Topographic engineering Tunnel engineering, Water engineering.
Environmental Testing Equipment
Features:
• Window CE operating system
• Color touch screen
• Laser prism free ranging
• Absolute coded angle measurement
• Two axis electronic compensation
• Convenient data exchange mode
• Rich application measurement program
• 1G memory mass data storage
Specification:
Wince total station DTM952R | ||
Distance measurement | ||
Maximum distance (under good weather conditions) | Single prism | 3.0 Km |
Three prisms | 5.0 Km | |
Non-prism | 400m or 600m (optional) | |
Numeric display | Maximum: 99999999.999 m minimum: 1mm | |
Accuracy | Non-prism: 5+3ppm; prism: 3+2ppm | |
Unit | m/ft (optional) | |
Measuring time | Fine measurement: 2s each time; tracking: 0.8s | |
Number of measurements | 1~99 measurements can be taken | |
Meteorological correction | It will automatically correct it with parameters entered | |
Atmospheric refraction and earth curvature correction | It will automatically correct it with parameters entered; K=0.14 | |
Prism constant correction | It will automatically correct it with parameters entered | |
Angle measurement | ||
Measurement mode | Absolute code | |
Grating disc diameter (horizontal, vertical) | 79mm | |
Minimum display reading | 1″ | |
Detection method |
Vertical disc: diameter Horizontal disc: diameter
|
|
Accuracy | 2″ | |
Telescope | ||
Imaging | Positive image | |
Barrel length | 170mm | |
Effective aperture of objective lens | 48mm | |
Magnifying ratio | 30× | |
Field angle | 1°30′ | |
Resolution | 3.5″ | |
Minimum focusing distance | 1.5m | |
Automatic vertical compensator | ||
System |
Single- or double-axis liquid electronic sensing and compensation |
|
Operating range | ±3′ | |
Accuracy | ±3 ″ | |
Level | ||
Level tube | 20″/2mm, 30″/2mm | |
Circular vial | 8′/2mm | |
Optical plummet | ||
Imaging | Positive image | |
Magnifying ratio | 3× | |
Focusing range | 0.5m~∝ | |
Field angle | 5° | |
Display | ||
Type | Double sides,lattice 240X320 LCD,3.5 inch touching screen operation | |
Operation System | Microsoft Windows CE.NET 5.0 | |
Data transmission | ||
Interface | RS-232C,USB,Bluetooth,SD-card | |
Onboard battery | ||
Power | Rechargeable mh-ni battery, rechargeable lithium battery | |
Voltage | Lithium battery: DC7.6V; mh-ni battery: DC7.2V | |
Continuous working hours |
4h |
|
Size and weight | ||
Overall dimensions | 174×207×383mm | |
Weight | 6.8㎏ |
