Hebei Better United Import And Export Co., Ltd.

INTERTEK Environmental Testing Equipment DTM624R Reflectorless Total Station

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DTM822R
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Environmental Testing Equipment Export standard package
Delivery Time: 3 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Reflectorless Total Station DTM624R Warranty: 1 Year
Dimensions: 174×207×383mm Weight: 12 Kg
Lithium Battery: DC7.6V Application: Environmental Testing Equipment
High Light:

INTERTEK Environmental Testing Equipment

,

DTM624R Reflectorless Total Station

Product Description

Reflectorless Total Station DTM624R Environmental Testing Equipment



Description:

Total stations are widely used in below fields, and are well received by worldwide surveyors and users.

Land surveying, Civil engineering, Topographic engineering Tunnel engineering, Water engineering.

Environmental Testing Equipment



Features:

  • Laser prism free ranging
  • Absolute coded angle measurement
  • Two axis electronic compensation
  • Simple and convenient operation
  • Large LCD display
  • Rich measurement procedures
  • Massive data storage

Specification:

DTM152M
Telescope
Image Erect
Magnification 30×
Effective aperture 48mm
Resolving power 3.75″
Minimum focus 1m
Stadia ratio 100
Sight distance precision ≤0.4%D
Tube length 165mm
Angle Measurement
Measuring method photoelectric detection by incremental encoder
Diameter of circle (vertical, horizontal) 79mm
Minimum reading 1″,5″,10″Selectable
Measuring unit 360°/400gon/6400mil Selectable
Vertical angle0° Zenith0°/Horizontal0°Selectable
Accuracy 2″
Distance Measurement
Single prism(under fair weather condition) 3km
Three prism(under fair weather condition) 5km
Non-prism(under fair weather condition) 400m
Display Max:999999.999m Min:1mm
Unit m/ft Selectable
Accuracy ±(3mm+2ppm·D)
Measuring time Fine single shot:3S Tracking:0.8 S
Meteorological Correction Manual input, Auto correction
Reflection prism correction Manual input, Auto correction
Vial
Plate vial 20″/2mm
Circular vial 8′/2mm
Vertical Compensator
System Liquid-electric detection
Compensation range ±3′
Resolving power 1″
Optical Plummet
Image Erect
Magnification
Focusing range 0.3m~∞
Field of view 5°
Display
Type LCD,Four lines,digital
Data Communication
Port RS-232C,USB
On-board Battery
Power resource Rechargeable Ni-H battery
Voltage DC7.2V
Continuous operation time BDC 3000mAh
Angle measurement: 20 hours
Distance measurement: 8 hours
Operation Environment
Operating temperature -20°~+45℃
Size & weight
Dimension 180mm×175mm×355mm
Weight 6.5kg

INTERTEK Environmental Testing Equipment DTM624R Reflectorless Total Station 0


About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Environmental Testing Equipment

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Environmental Testing Equipment

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
