Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | BTU-DTM822R |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Environmental Testing Equipment Export standard package |
Delivery Time: | 3 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Electronic Total Station DTM152M | Warranty: | 1 Year |
---|---|---|---|
Dimensions: | 174×207×383mm | Weight: | 12 Kg |
Lithium Battery: | DC7.6V | Application: | Environmental Testing Equipment |
High Light: | DTM152M electronic total station machine,Electronic Total Station Machine DC7.6V |
Product Description
Electronic Total Station DTM152M Environmental Testing Equipment
Description:
Total stations are widely used in below fields, and are well received by worldwide surveyors and users.
Land surveying, Civil engineering, Topographic engineering Tunnel engineering, Water engineering.
Environmental Testing Equipment
Specification:
DTM152M | |
Telescope | |
Image | Erect |
Magnification | 30× |
Effective aperture | 48mm |
Resolving power | 3.75″ |
Minimum focus | 1m |
Stadia ratio | 100 |
Sight distance precision | ≤0.4%D |
Tube length | 165mm |
Angle Measurement | |
Measuring method | photoelectric detection by incremental encoder |
Diameter of circle (vertical, horizontal) | 79mm |
Minimum reading | 1″,5″,10″Selectable |
Measuring unit | 360°/400gon/6400mil Selectable |
Vertical angle0° | Zenith0°/Horizontal0°Selectable |
Accuracy | 2″ |
Distance Measurement | |
Single prism(under fair weather condition) | 3km |
Three prism(under fair weather condition) | 5km |
Display | Max:999999.999m Min:1mm |
Unit | m/ft Selectable |
Accuracy | ±(3mm+2ppm·D) |
Measuring time | Fine single shot:3S Tracking:0.8 S |
Meteorological Correction | Manual input, Auto correction |
Reflection prism correction | Manual input, Auto correction |
Vial | |
Plate vial | 20″/2mm |
Circular vial | 8′/2mm |
Vertical Compensator | |
System | Liquid-electric detection |
Compensation range | ±3′ |
Resolving power | 1″ |
Optical Plummet | |
Image | Erect |
Magnification | 3× |
Focusing range | 0.3m~∞ |
Field of view | 5° |
Display | |
Type | LCD,Four lines,digital |
Data Communication | |
Port | RS-232C,USB |
On-board Battery | |
Power resource | Rechargeable Ni-H battery |
Voltage | DC7.2V |
Continuous operation time | BDC 3000mAh Angle measurement: 20 hours Distance measurement: 8 hours |
Operation Environment | |
Operating temperature | -20°~+45℃ |
Size & weight | |
Dimension | 180mm×175mm×355mm |
Weight | 6.5kg |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Environmental Testing Equipment
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Environmental Testing Equipment
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
