BTU-MABPT Asphalt Testing Equipment Manual Breaking Point Tester

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-MABPT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Manual Asphalt Breaking Point Tester Asphalt Testing Equipment Warranty: 1 Year
Thermometer: -38°C~+30°C,division Value 0.5°C Size Of Sample Sheet: 41mm×20mm×0.15mm
Weight Approx: 3 Kg Application: Asphalt Testing Equipment
High Light:

BTU-MABPT Asphalt Testing Equipment

,

BTU-MABPT breaking point tester

Product Description

Manual Asphalt Breaking Point Tester Asphalt Testing Equipment



Features:

  • The instrument is composed of outer cylinder, temperature preservation cylinder, thermometer, lower plate, upper grip,fi xing rod, base, guide rail, sweeping block, handle, steelsheet and so on.
  • The temperature preservation cylinder is a double layer glass cylinder. It is used to place the dry ice and ethylalcohol mixtures. It is the cooling unit.
  • The lower plate and upper grip are metal sheets.The fi xing rod and movable rod are made of fabroil.
  • The base, guide rail, sweeping block and handle are used to changer the relative position of fi xing rod and movable rod to make the sample sheet bending.
  • Asphalt Testing Equipment

Description:

Used for determining the breaking point of solid and semi-solid bitumens. The Fraas Breaking Point is the temperature at which bitumen first becomes brittle, as indicated by the appearance of cracks when a thin-film of the bitumen on a metal plaque is cooled and flexed in accordance with specified conditions Asphalt Testing Equipment



Specification:

Thermometer -38°C~+30°C,division value 0.5°C
Size of sample sheet 41mm×20mm×0.15mm
Weight approx. 3 kg
