SGS Certified Asphalt Testing Equipment 20L Laboratory Asphalt Mixer

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-LAM
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: 20L Laboratory Asphalt Mixer Asphalt Testing Equipment Ambient Humidity: ≤ 80%.
Ambient Temperature: (- 5 ~ + 50) ℃ Total Weight (net Weight): 215kg.
Mixing Volume: 20L. Application: Asphalt Testing Equipment
High Light:

SGS Asphalt Testing Equipment

,

20L Laboratory Asphalt Mixer

Product Description

20L Laboratory Asphalt Mixer Asphalt Testing Equipment​



Features:

1. This instrument adopts advanced microcomputer control technology. It can set the mixing temperature arbitrarily within room temperature - 250 ℃, and automatically adjust and control the PID. It can automatically control the mixing time and realize the operation automation.

2. With phase sequence protection function, it can avoid mechanical damage caused by phase sequence error.

3. The instrument is of floor type structure, with novel design, reasonable structure and convenient use.

4.20L Laboratory Asphalt Mixer Asphalt Testing Equipment



Description:

It is applicable to mixing of asphalt mixture test pieces before fabrication.

The instrument adopts advanced microcomputer control technology, sets the mixing temperature arbitrarily within room temperature ~ 200 ℃, and automatically performs PID adjustment control. It can automatically control the mixing time and realize operation automation; With phase sequence protection function, it can avoid mechanical damage caused by phase sequence error.

This instrument is small in size, saves the laboratory space, and is easy to operate. It is the first choice for asphalt mixture mixing by asphalt production enterprises, highway and bridge construction units, and relevant colleges and universities and research institutions. Asphalt Testing Equipment



Specificationl:

Mixing volume 20L
Temperature control range room temperature ~ 200 ℃
Temperature control accuracy ± 3 ℃
Time control range (0 ~ 999) seconds
Time control accuracy ± 0.1s
Mixing paddle speed 47 revolutions / min; Rotate 76 turns / min
Mixing motor AC 380 V, 550 W; 1400 rpm; 50 Hz
Lifting motor AC 380 V, 250 W; 1400 rpm; 50 Hz
Overall dimension 600mm × 400㎜ × 1300 mm (length × wide × High)
Total weight (net weight) 215kg
Working power supply AC (380 ± 10%) V; 16A; 50Hz (three-phase four wire system with zero line)
Ambient temperature (- 5 ~ + 50) ℃
Ambient humidity ≤ 80%
