PLC Control Asphalt Testing Equipment 0~999 Times Asphalt Gyratory Compactor

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-CC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Gyratory Compactor Rotation Angle: 0 ~ 20 ° ± 0.02 ° Adjustable
Compaction Times: 0 ~ 999 Times Rotary Compaction Angle Accuracy: Less Than 0.01 °
Displacement Range: 0 ~ 250mm Application: Asphalt Testing Equipment
High Light:

PLC Control Asphalt Testing Equipment

,

999 times asphalt gyratory compactor

Product Description

Gyratory Compactor Asphalt Testing Equipment



Features:

Imported PLC control, computer and microcomputer control operation, real-time display of various parameters and display of various curves and charts through the interface and microcomputer, and non-interference connection with the touch screen to jointly control the instrument.Asphalt Testing Equipment



Description:

Meet the requirements of test code for asphalt and asphalt mixture of highway engineering JTG e20-2011 to measure and display in real time the internal angle, compaction pressure, rotation times and specimen height of the test mold.

In the laboratory, the volume properties and engineering properties of the actual pavement materials are simulated. Under the three main technical conditions of constant vertical pressure, constant compaction angle and specified compaction speed, the test pieces are rotated in a constant speed circular cycle along the eccentric angle, compacted at constant pressure, and then rotated and leveled at constant pressure to remove the eccentric angle. The test process of preparing the cylinder test pieces of hot mixed asphalt mixture is completed.Asphalt Testing Equipment



Specification:

Rotation angle 0 ~ 20 ° ± 0.02 ° adjustable
The pressure is better than 100 to 1000kPa, and the speed is continuously adjustable
Compaction times 0 ~ 999 times
Rotation times

0-1000 times of normal rotation (according to the set compaction angle);

Reverse rotation (compaction angle is 0 °) 0-500 times

Rotary compaction angle accuracy less than 0.01 °
Displacement range 0 ~ 250mm

PLC Control Asphalt Testing Equipment 0~999 Times Asphalt Gyratory Compactor 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
