Tag Open Cup Flash And Fire Point Test Apparatus 0 ~ 1000W Adjustable

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: LHYT-0633
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Tag Open-Cup Flash And Fire Point Tester Electric Furnace Heating Power: 0 ~ 1000W Continuous Adjustable
Power Supply: 220V ± 10% 50Hz Ambient Temperature: - 10 ℃ ~ 50 ℃
Relative Humidity: ≤ 85% Application: Asphalt Testing Equipment
High Light:

Flash And Fire Point Test Apparatus 1000W

,

open cup flash point apparatus 1000W

Product Description

Tag Open-Cup Flash And Fire Point Tester Asphalt Testing Equipment



Features:

1 automatic sweeping and ignition;

2 electric furnace heating power 0 ~ 1000W continuous adjustable;

3 the heating wire is protected by transparent quartz tube, without open fire, explosion-proof, and fast heating speed;

4 the instrument adopts a metal crucible with a depth of 47mm, a diameter of 64mm at the upper mouth and a diameter of 38mm at the lower mouth. There is a scale at 3.2mm below the cup mouth. The metal crucible must not be heated by sand bath or other open fire, and must be supported in the thermal insulation liquid bath to ensure safety.

5 gauge: the thickness is 3.2mm, and there are two 3.2mm ± 0.25mm protrusions under it. There are two small holes with diameters of 4.0mm and 0.8mm at 3.2mm from the bottom.

6 thermal insulation bath: made of copper. For those with flash point lower than 79.5 ℃, the water tank can be used directly. For those with flash point higher than 79.5 ℃, the 1:1 mixture of water and ethylene glycol is used as the medium.

7.Asphalt Testing Equipment



Description:

This instrument is suitable for measuring the flash point of liquid petroleum asphalt materials with a flash point lower than 93 ℃ with a tiger open cup (TOC) to evaluate the construction safety Asphalt Testing Equipment.



Specification:

Power supply 220V ± 10% 50Hz
Ambient temperature - 10 ℃ ~ 50 ℃
Relative humidity ≤ 85%

Tag Open Cup Flash And Fire Point Test Apparatus 0 ~ 1000W Adjustable 0
