220Volt Asphalt Testing Equipment 0-50mm Range Semi Automatic Penetrometer

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-SAP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Semi Automatic Penetrometer Minimum Grading: 0.01mm
Measuring Range: 0-50mm Weight Of Needle And Gauge: 100±0.05g
Power Supply: 220V/50HZ Application: Asphalt Testing Equipment
High Light:

50mm Semi Automatic Penetrometer

,

220Volt Asphalt Testing Equipment

Product Description

Semi Automatic Penetrometer Asphalt Testing Equipment



Features:

1. Precision displacement measuring device.

2. Adjustable within 0-99 seconds, and the time error is less than ± 0.1 seconds.

3. Needle insertion accuracy: 0.01mm.

4. Maximum penetration depth: 40mm.

5. Standard needle: the total weight of needle and needle rod is 2.5 ± 0.05g, which meets the specification requirements of GB / t4509 and t0604.

6. Flat bottom glass dish: it is a hard glass cylinder with a volume greater than 1.5L and a depth greater than 80mm. A sample holding dish support is arranged inside to make it stable.

7. Sample dish: copper, cylindrical, flat bottom. The inner diameter of the sample holding dish is 55mm and the depth is 35mm (applicable to the sample with penetration less than 200).

8. Lifting support: it can be freely adjusted to facilitate the needle tip to align with the sample plane Asphalt Testing Equipment



Description:

It is applicable to the penetration of residue after evaporation of road petroleum asphalt, modified asphalt and liquid petroleum asphalt or emulsified asphalt Asphalt Testing Equipment



Specification:

Minimum grading 0.01mm
Measuring range 0-50mm
Weight of needle and gauge 100±0.05g
Power supply 220V/50HZ
Sample plate Ф 55 * 35 mm flat brass tubular plate
Heat preservation plate

Volume:> 15L Raw material:glass

Depth:>60mm. Shape: flat tubular plate

220Volt Asphalt Testing Equipment 0-50mm Range Semi Automatic Penetrometer 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
