AC380V 50Hz Accelerated Polishing Machine Aggregate Testing Machine

Product Description

Accelerated Polishing Machine Aggregate Testing Equipment

Standard:

EN 1097-8 EN 1341 EN 1342 EN 1343 BS 812:114 NF P18-575 CNR N.105

Description:

It is used for indoor simulation of the polishing effect of automobile tires on the road surface. By accelerating the polishing of the aggregate used for the road surface, the polishing value of the aggregate is measured to evaluate the anti polishing performance of the aggregate, so as to provide scientific basis for selecting appropriate surface aggregate to pave sections with different friction coefficient requirements and for reasonably developing and utilizing stone resources, and create conditions for shortening the research period of anti-skid pavement, It provides technical reference for developing high quality artificial aggregate.

Structure:

• Transmission mechanism: including motor, synchronous gear, rubber wheel assembly, etc., used to transmit power and change speed ratio.
• Road wheel device: used to install 14 test pieces.
• Sand sliding device: it is composed of sand bucket, support and sand sliding mechanism, which is used to store abrasive and control sand sliding.
• Water supply system: including water storage bracket, water supply vessel, flowmeter and water pipe, which is used to control the water flow.
• Load adjustment mechanism: including handwheel and cam, which is used to support counterweight and adjust the pressure between rubber wheel and road wheel.
• Counterweight device: including lever, counterweight and shield, which is used to ensure the specified pressure on road wheels.
• Test mold: used for making stone polishing test pieces.
• Electric control device: it is used to control the number of revolutions required by the road wheel and the amount of sand.

• Aggregate Testing Equipment



Specification:

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Aggregate Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
