Steel 75mm Aggregate Crushing Value Apparatus With Cylinder Plunger

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-ACV)
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Aggregate Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Aggregate Crushing Value Apparatus (ACV) Aggregate Testing Equipment Standard: BS 812:110
Warranty: 1 Year Material: Steel
Cylinder Nominal Diameter: 75mm Plunger And Base Plate Weight: 3.5KG
High Light:

Steel Aggregate Crushing Value Apparatus

,

75mm Aggregate Crushing Value Apparatus

Product Description

Aggregate Crushing Value Apparatus (ACV) Aggregate Testing Equipment



Standard:

BS 812:110



Description:

The aggregate crushing value provides a relative measure of the resistance of an aggregate to crushing under a gradually applied compressive load. Supplied complete with cylinder, plunger, base plate, tamping rod, and measure.Aggregate Testing Equipment .



Specification:

Dia.75mm product parameter:

Product name Aggregate Crushing Value Apparatus
Material Steel
Cylinder nominal diameter 75mm
Metal Measure size (Dia.xH)57x90mm
Tamping Rod (Dia.xL)8X300mm
Plunger and base plate Weight 3.5KG
Cylinder Internal diameter.A 78±0.5mm
Internal Deep.B 70mm to 85mm
Minimum wall thicks.c 8mm
Plunger Diameter of piston,D 76±0.5mm
Diameter of atem,E >45.0 to ≤D mm
Overall length of piston plus stem,F 60mm to 80mm
Minimum depth of piston,G no less than 19.0mm
Diameter of hole ,H 10±0.1
Baseplate Minimum thickness,I 10mm
Length of each side of aquare,J 110mm to 115
Total weight 5Kg

Dia.150mm product parameter:

Product name Aggregate Crushing Value Apparatus
Material Steel
Cylinder nominal diameter 150mm
Metal Measure size (Dia.xH)115x180mm
Tamping Rod (Dia.xL)16X600mm
Plunger and base plate Weight 16.6KG
Cylinder Internal diameter.A 154±0.5mm
Internal Deep.B 125mm to 140mm
Minimum wall thicks.c 16mm
Plunger Diameter of piston,D 152±0.5mm
Diameter of atem,E >95 to ≤D mm
Overall length of piston plus stem,F 100mm to 115mm
Minimum depth of piston,G no less than 25.0mm
Diameter of hole ,H 20±0.1
Baseplate Minimum thickness,I 10mm
Length of each side of aquare,J 200mm to 230mm
Total weight 20Kg
