Resolution Ratio 0.01KN Shear Box Test Apparatus Rock Tester ASTM D5607

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: YSZJ-50
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Rock Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Resolution Ratio 0.01KN Rock Shear Box Apparatus Rock Testing Equipment Standard: ASTM D5607
Warranty: 1 Year Normal Pressure: Max 500KN/0.01KN
Lateral Shear: Max 300KN/0.01KN Travel Of Piston: 0-100mm
High Light:

0.01KN Shear Box Test Apparatus

,

Rock Tester ASTM D5607

Product Description

Resolution Ratio 0.01KN Rock Shear Box Apparatus Rock Testing Equipment



Standard:

ASTM D5607



Description:

The technique enables the engineer to select specimens of rock from exposed faces or bore holes, observe orientation of fault lines, then set and test the fault in the shear box. The apparatus consists of a diagonally split box assembly. The upper half incorporates a vertical ram for compressive loading, and the lower half, two horizontal rams for reversible shearing action. The force applied by the horizontal ram is aligned with the centre of the box and the discontinuity in the specimen. Pressure is applied to the rams by means of hand-operated hydraulic pumps.Rock Testing Equipment



Specification:

Model NO YSZJ-50
normal pressure Max 500KN/0.01KN
lateral shear Max 300KN/0.01KN
travel of piston 0-100mm
Specification of direct cutting box φ50*50
Dimension 67x77x33CM
Weight 300KG
Displacement measurement Diaguge 10mm/0.01mm

Configuration table:

Discripation QTY
Main Body 1 unit
Specimen box 6PCS
Hydraulic Pumps 2Units
Pressure gauges 2PCS
Dial gauge 2PCS
Tools 1set



Resolution Ratio 0.01KN Shear Box Test Apparatus Rock Tester ASTM D5607 0
