575mm Drop Manual Dynamic Penetrometer Test 30 60 90 Degree Cone

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-DC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden box Soil Testing Equipment
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: DCP Dynamic Cone Penetrometer Hammer: 8kg 9kg 10kg
Drop: 575mm Dimensions: 310x1160x190 Mm
Cone: 30 60 90 Degree Application: Soil Testing Equipment
High Light:

30 degree DCP Dynamic Cone Penetrometer

,

90 degree DCP Dynamic Cone Penetrometer

,

575mm Drop dynamic penetrometer test

Product Description

Manual Dynamic Penetrometer Soil Penetrometer (DCP) Soil Testing Equipment



DCP Dynamic Cone Penetrometer Soil Testing Equipment



Standards:

ASTM D698, D1557,D1883;EN 13286-2;BS 1377:4;AASHTO T99 ,T180 ,T193



Description:

Dynamic Cone Penetrometer is designed to obtain a direct and rapid in-situ evaluation of the structural strength of road pavement layers constructed with unbound materials. Soil Testing Equipment



The equipment consists of:

  • Drop sliding hammer 8 kg weight, falling height of 575 mm,Optional hammer 10 kg,
  • Penetration rod,
  • 3 piece 60° cone,
  • Metal plate coupling for ruler,
  • Segmented adaptor for extension rods,
  • Segmented upper extension rod,
  • Segmented lower extension rod,
  • Spanners,hex wrench,
  • Users Manual
  • Steel ruler,
  • Alloy aluminum carrying case
  • Soil Testing Equipment

Features:

  • Portable, hand-operated equipment.
  • The DPC Penetrometer results can be compared and interpreted with CBR (California Bearing Ratio) as per sperimental Kleyn 1982 studies.).
  • Field calibration of a portable dynamic cone penetrometer was made to determine a penetration resistance relationship with the standard penetration resistance.
  • The penetrometer has been found useful in the inspection of footing foundations and for light field exploration where the standard penetration range of limits is generally known
  • Soil Testing Equipment

Specification:

Dimensions 310x1160x190 mm
Weight 27 kg



575mm Drop Manual Dynamic Penetrometer Test 30  60 90 Degree Cone 0575mm Drop Manual Dynamic Penetrometer Test 30  60 90 Degree Cone 1
