80L Constant Head Permeability Cells Coarse Grained Soil Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: CLTS-10751
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden box Soil Testing Equipment
Delivery Time: 5-8 work days Soil Testing Equipment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Constant Head Permeability Cells Coarse Grained Soil Warranty: 1 Year
Inner Diameter Of Metal Barrel: 300mm Metal Bucket Height: 500mm
Metal Bucket Wall Thickness: 10mm Water Supply Tank Capacity: 80L
High Light:

Coarse Grained Soil Testing Equipment

,

Constant Head Permeability Cells

,

80L Permeability Cells

Product Description

Constant Head Permeability Cells Coarse Grained Soil Soil Testing Equipment


Description:

The equipment is used to determine the permeability coefficient of coarse-grained soil and graded crushed stone with a maximum particle size of no more than 75mm, and meets the standard TB 10751-2018 "Construction Quality Acceptance Standard for High Speed Railway Roadbed Engineering". Soil Testing Equipment



Applicable scope:

The coarse grained soil permeability tester is a constant head tester designed and manufactured in accordance with the requirements of the "TB 10751-2018 High Speed Railway Roadbed Engineering Construction Quality Acceptance Standard". This instrument is used to determine the permeability coefficient of coarse-grained soil and graded crushed stone with a particle size of no more than 75mm



Technical parameters:

  • Inner diameter of metal barrel: 300mm
  • Metal bucket height: 500mm
  • Metal bucket wall thickness: 10mm
  • Water supply tank capacity: 80L
  • Number of pressure measuring tubes: 5
  • Inner diameter of pressure measuring tube: 6mm
  • Pressure measuring hole spacing: 50mm
  • Graduation value of pressure measuring tube: 1mm
  • Diameter of seepage pipe: 16mm
  • Overflow pipe diameter: 16mm
  • Permeable plate aperture: 3.5mm


Specification:

Inner diameter of metal barrel 300mm
Metal bucket height 500mm
Metal bucket wall thickness 10mm
Water supply tank capacity 80L
Number of pressure measuring tubes 5
Inner diameter of pressure measuring tube 6mm
Pressure measuring hole spacing 50mm
Graduation value of pressure measuring tube 1mm
Diameter of seepage pipe 16mm
Overflow pipe diameter 16mm
Permeable plate aperture 3.5mm

80L Constant Head Permeability Cells Coarse Grained  Soil Testing Equipment 0
