Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | BTU |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 |
Price: | Negotiable |
Packaging Details: | Standard export wooden box Soil Testing Equipment |
Delivery Time: | 5-8 work days Soil Testing Equipment |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Portable Hydraul Static Cone Penetrometers | Warranty: | 1 Year |
---|---|---|---|
Rated Penetration Force: | 20KN /30KN /35KN | Pulling Force: | 22KN /32KN /37KN |
Cylinder Stroke: | 400mm /500mm /500mm | Application: | Soil Testing Equipment |
High Light: | 30KN Static Cone Penetrometers,20KN Static Cone Penetrometers,Portable Hydraulic Soil Testing Equipment |
Product Description
Portable Hydraul Static Cone Penetrometers Soil Testing Equipment
Description:
At a certain speed, the probe is pressed into the soil using static force, and the pressure sensor inside the probe is used to record the penetration resistance of the probe to the soil through a recorder. Soil Testing Equipment
Features:
1. Breaking through the previous concept of hydraulic static testing machines, the smallest dual cylinder hydraulic static testing machine.
2. The complete equipment can be placed in the trunk of an SUV.
3. Two people can complete all operations safely and reliably.
4. It can be used for power system line survey, large-scale soft foundation treatment and detection, etc.
5. Suitable for 5cm2, 10cm2 single or double bridge static probes, cross plates, or other multifunctional probes.
6. It can be equipped with 5cm2, 10cm2 single or double bridge static probes, cross plates, or other multifunctional probes.
Specification:
Series specifications | Rated penetration force | Pulling force | Cylinder stroke |
TSY-2.2 | 20KN | 22KN | 400mm |
TSY-3 | 30KN | 32KN | 500mm |
TSY-3.5 | 35KN | 37KN | 500mm |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments
