Triplex Consolidation Apparatus Single Lever Low Pressure Soil Testing

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-TCASLLP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Direct - Residual Shear Test Machine Digital Four Dimensional Stepless Speed Regulation Standard: ASTM/AASHTO/BS/CEN-ISO
Power Supply: 220v Load Arm: 12:1, 10:1
Load Pressure: 125.Kpa-800Kpa/30cm2、125.Kpa-400Kpa/50cm2 Sample Area: 30cm2, 50cm2
Instrument Structure: Steel Structure Consolidated Container: 1 × Beam、2 × Beams、3 × Beams

Product Description

Triplex Consolidation Apparatus Single Lever Low Pressure Soil Testing Machine



Standards:

GB/T 4935.1-2008 Geotechnical Test Instruments - Oedometer - Part 1: Single Lever Oedometer



Description:

This instrument is used for soil compression test to determine the relationship between soil deformation and pressure or void ratio and pressure, and the relationship between deformation and time, so as to calculate the unit settlement weight, compression system, compression index, rebound index, compression modulus and consolidation coefficient of soil. The measurement items depend on the needs of the project​



Product mix:



1. There are three sets of soil sample containers in each instrument of the soil sample container. When available, three soil sample tests can be carried out. Each set of container can be used to carry out two types of soil sample area tests of 30cm2 and 50cm2, respectively. The height of soil samples is 2cm, as shown in the attached figure (1).

2. Lever type (with level gauge): the lever ratio is 1:12, 1:10, and the maximum output of medium pressure is 4.8 kn, and the load is applied in stages. There are nine levels from 12.5 to 800KPa for 30cm2, eight levels from 12.5 to 800KPa for 50cm2, and the maximum output of low pressure is 2.4KN. There are eight levels from 12.5 to 800KPa for 30cm2 by step loading (seven levels from 12.5 to 800KPa for 50cm2). See the attached table (1) for details.

The lever fulcrum can rise and fall 1.5cm. During the test, first adjust the lever to the horizontal position. When the soil sample sinks under pressure, causing the lever to tilt, rotate the handwheel counterclockwise to lower the lever fulcrum so that the lever can return to the horizontal state, so as to ensure the accuracy of the load at all levels.

3. There are four holes at the bottom of the instrument frame for installation, and the platen is used for making high-density boards





Specification:

Load pressure  125.Kpa-800Kpa/30cm2, 125.Kpa-400Kpa/50cm2
Consolidated container  1 × beam,2 × beams,3 × beams
Load arm  12:1, 10:1
Sample area 30cm2, 50cm2
Instrument structure  steel structure
Power supply AC220V ± 10%50hz

Triplex Consolidation Apparatus Single Lever Low Pressure Soil Testing 0Triplex Consolidation Apparatus Single Lever Low Pressure Soil Testing 1
