Ford Cup Paint Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-BGD
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Ford Cup Standard: ASTM D1200, D333, D365
Warranty: 1 Year Cup Capacity: 100ml ± 1ml
Material: Cup Body - Aluminum Alloy; Bore - Stainless Steel Inner Diameter Of Cup Body: 50mm ± 0.05mm

Product Description

Ford Cup Paint Testing Equipment



Standard:

ASTM D1200, D333, D365



Description:

It is made according to ASTM D1200, d333 and D365 standards for paints and raw materials of American Society for testing and materials, and is used to measure the viscosity of ink, paint and paint. It is made of a high-quality aluminum cup with a small hole at the bottom and a capacity of about 100ml. It is widely used in America and Europe to evaluate the viscosity of materials by measuring the time required for a certain volume of sample in the aluminum cup to flow out from the small hole at the bottom.Paint Testing Equipment



Specification:

material cup body - aluminum alloy; Outflow nozzle - stainless steel
capacity 100ml ± 1ml
inner diameter of cup body 50mm ± 0.05mm
outer diameter of cup body 86mm ± 0.1mm
length of outflow hole 10mm ± 0.1mm



technical parameter

Ford cup

(2#)

Ford cup
(3#)

Ford cup

(4#)

Portable Ford cup(4#)

Ford cup

(5#)

Internal vertical height 43±0.1mm 43±0.1mm 43±0.1mm 43±0.1mm 43±0.1mm
Outlet aperture ф(mm) 2.53 mm 3.40 mm 4.12 mm 4.12 mm 5.20 mm
Measuring range(Centistokes) 25-120 49-220 70-370 70-370 215-1413
Outflow time(sec)±0.2 40-100 25-105 20-105 20-105 20-105
model BGD 125/2 BGD 125/3 BGD 125/4 BGD 125/4P BGD 125/5
