Zahn Cup Paint Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-BGD
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Zahn Cup Standard: ASTM D 4212
Warranty: 1 Year Cup Body Material: Corrosion Resistant And Solvent Resistant Stainless Steel
Measurement Range: 20cst-1800cst Cup Volume: 43ml ~ 49ml

Product Description

Zahn Cup Paint Testing Equipment

Description:
It is designed according to ASTM D 4212 and is used to measure the viscosity of Newtonian or quasi Newtonian liquids. It can be used in workshops, factories and laboratories to quickly check and adjust the viscosity of various fluids. The appropriate cup number shall be selected before use to control the outflow time between 20 seconds and 80 seconds. The viscosity cup is widely used in ink and printing industries.

Each Cairn cup is strictly calibrated with Newton standard oil traceable to NIST oil before delivery. Each cup is marked with the corresponding calibration coefficient "K".

Each dip cup has a 12 inch long ring handle, which can be held by hand to immerse the dip cup into the liquid container. There is a finger ring in the center of the handle, which is convenient for the dip cup to keep the vertical position during use.

The results obtained for a specific soaking cup should be expressed in "zean seconds" at a specified temperature. To convert "zean seconds" to centistokes, see the following formula (ASTM D 4212).

V=k(t-c)

V - kinematic viscosity, CST; T - outflow time, s; k. C - corresponding constant

Note: centistoke × Specific gravity = centipoise
 Paint Testing Equipment

Specification:



cup body material corrosion resistant and solvent resistant stainless steel
measurement range 20cst-1800cst
cup volume 43ml ~ 49ml
calibration certificate attached



model

Aperture

(mm)

Test range (CST) application k c
BGD 126/1 1.98(0.08in) 5~60 Very thin liquid 1.1 29
BGD 126/2 2.74(0.11in) 20~250 Side pressure adjustment of thin oil, varnish, enamel and offset printing ink 3.5 14
BGD 126/3 3.76(0.15in) 100~800 High viscosity coatings and inks (offset printing ink production) 11.7 7.5
BGD 126/4 4.27(0.17in) 200~1200 Higher viscosity coatings and inks 14.8 5
BGD 126/5 5.28(0.21in) 400~1800 Screen printing ink 23 0

Zahn Cup Paint Testing Equipment 0
