Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | BTU-sata |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Paint Testing Equipment Standard export wooden box |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | SCRUB ABRASION TESTER ASTM | Warranty: | 1 Year |
---|---|---|---|
Standard: | ASTM D 3450 ASTM D 4213 ASTM D 4828 ASTM D 2486 ISO 11998 | Brush Load: | 450 G ± 10 G |
Travel: | 300mm. | Net Weight: | 27 Kg |
High Light: | ASTM Wet Abrasion Scrub Tester,Wet Abrasion Scrub Tester 300mm |
Product Description
Scrub Abrasion Tester ASTM Paint Testing Equipment
Standard:
ASTM D 3450 ASTM D 4213 ASTM D 4828 ASTM D 2486 ISO 11998
Matters needing attention:
■ in order to ensure the accuracy and reproducibility of the test data, please select uniform substrates and prepare samples according to the same coating process
■ before use, please immerse the brush in 20 ℃ water for 30min, then press it to dry, and then immerse it in the prepared cleaning solution for 10min
■ when the bristles are worn to a length less than 16mm, the brush must be replaced
■ the result judgment is based on the coating damage in the area with the middle length of 100mm of the test plate
Performance characteristics:
◆ the operating speed can be set to meet the requirements of various standards
◆ four digit counter, start the instrument and automatically stop after the set number of times
◆ compatible with a variety of friction heads to meet ISO, ASTM, DIN and GB standards.
◆ it is very convenient and fast to load and unload the test sample and replace the friction head.
◆ not affected by voltage frequency
◆ push rod design, stable and uniform running speed
◆ double slide design can conduct two tests at the same time
◆ rugged design and durable use
◆ the whole machine is made of anodized aluminum, with stable test and strong repeatability of test results, even at the fastest friction speed
◆ the solution (washing medium) flows into the brush through the peristaltic pump on the side of the instrument, and the dripping acceleration of the washing medium can be precisely adjusted
Description:
The surface to be coated (coating film) needs to be evaluated by brush, sponge or other methods for its scrub resistance. Therefore, there is a need for a precision instrument that can produce a repeatable and controlled condition to simulate the wear pattern of the coating film every day. The scrub resistance tester designed by Bagda can effectively evaluate the washability of the coating film and the performance related to the abrasion resistance of the coating, and can also evaluate the performance of the detergent by means of reproduction test.
This is the latest multi-functional anti scrubbing instrument, which can be compatible with a variety of domestic and international test standards. These instruments are solid and reliable, with many functions. They can test the abrasion resistance, washing resistance, brush resistance and impedance performance of a variety of materials, including pigments, paints, inks, coatings, leather, wood, plastics, printing materials and fabrics.Paint Testing Equipment
Specification:
brush load | 450 g ± 10 g |
operating speed | 5 ~ 95 times / min (continuously adjustable) |
travel | 300mm |
operation times | 0 ~ 9999 (arbitrarily set) |
input voltage | AC 110V / 220V; 50/60HZ |
glass plate size | 430mm × 306mm |
washing medium bottle capacity | 1L |
overall dimension | 590mm × 460mm × 300mm |
net weight | 27 kg |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Paint Testing Equipment
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Paint Testing Equipment
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
