SGS Paint Inspection Equipment 20mm Punch Coating Cupping Tester

Product Description

Coating Cupping Tester Digital High-Quality Paint Testing Equipment

Features:

◆ automatic coordinate positioning system: after the machine is zeroed, it automatically memorizes and tracks the coordinate position of the punch (when the instrument is not powered on), eliminating the error caused by the return and shaking of the traditional machine in operation

◆ adopt high-precision position sensor, and the measurement resolution of indentation depth can reach 0.01mm

◆ suitable for coating test on any substrate, the maximum indentation force can reach 2500n

◆ the zero coordinate position of the punch can be manually reset and memorized

◆ it is equipped with a 10 times light magnifying glass that meets the standard requirements to facilitate observation and judgment of test results

◆ manual operation, convenient and labor-saving.

Description:

It is to evaluate the anti cracking or anti separation performance of the coating after it is gradually deformed under standard conditions after film formation. The minimum depth of the punch when the paint film is damaged is the cupping index (also known as Erichsen number), expressed in mm. Its structure is a bench type device with a steel body and a steel ball test head with a diameter of 20mm, also known as a punch. Press the unpainted side of the test plate with a certain force; Rotate the hand wheel at a certain speed (recommended: 0.2mm/s) to top the steel ball, and observe the surface of the test plate through a magnifying glass. When the test plate is deformed and the first crack is observed, immediately stop rotating the hand wheel and read out the cup convex depth value from the LCD screen.

This machine is designed according to GB / T 9753, DIN ISO 1520 and BS 3900. It is mainly applicable to the coating of metal plates in the household appliance industry (measuring the stretch and adhesion of paint film on the metal surface), and also applicable to the coating on some non-metal substrates.Paint Testing Equipment

Specification:

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Paint Testing Equipment

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Paint Testing Equipment

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
