Hebei Better United Import And Export Co., Ltd.

T Bend Tester High-Precision Paint Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-TBTHP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: T Bend Tester High-precision Warranty: 1 Year
Standard: GB/T 30791-2014 ISO 17132-2008 One Bend Angle: <45 °
Machine Weight: 50kg Dimensions: 300 * 300 * 190mm

Product Description

T Bend Tester high-precision Paint Testing Equipment



Standard:

GB/T 30791 ISO 17132



Features:

Turn the painted surface to the outside of the bend, and bend the painted test plate 180 ° back to its back with a gradually decreasing radius of curvature, wherein the radius of curvature is determined by the spacer. After the test plate is bent, check the coating cracking of each sample plate through a magnifying glass and observe the peeling of the coating through a tape pull-off test. The T-bend rating is used to indicate the minimum diameter of the test plate that can be bent without the occurrence of coating cracking or peeling, that is, without passing. Or visual inspection through a magnifying glass to determine whether the coating film has any form of peeling.



Description:

  • It complies with the requirements of folding method (repeated folding around the test plate itself) in GB / T 30791 (the main drafting unit of this standard) and ISO 17132 T-bend test of paints and varnishes. It has the characteristics of compact structure, simple appearance and convenient use. It is an ideal equipment for measuring the bending resistance of color steel plate and aluminum plate.Paint Testing Equipment



Specification:

test substrate steel plate thickness ≤ 1.0mm; Aluminum plate thickness ≤ 2.0mm
overall weight 50kg
overall dimension 350mm × 300mm × 670mm (including handle)

T Bend Tester High-Precision Paint Testing Equipment 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Paint Testing Equipment

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Paint Testing Equipment

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
