Load 500g 1000g Coating Hardness Tester Pencil Hardness Tester For Paint

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-PPHT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: PORTABLE PENCIL HARDNESS TESTER Standard: GB/T6739-2006,ASTMD3363,ISO15184,BS3900-E19,ECCA-T4/1,JIS,CNS
Warranty: 1 Year Load Weight : 1000g /750g /500g
Scratch Speed: About 1 Mm/s Three Touch Points: Two Wheels, A Pencil Core
High Light:

1000g Coating Hardness Tester

,

500g Pencil Hardness Tester For Paint

Product Description

Portable Pencil Hardness Tester Paint Testing Equipment



Standard:

GB/T6739-2006,ASTMD3363,ISO15184,BS3900-E19,ECCA-T4/1,JIS,CNS



Features:

Coating hardness is the necessary measurement for the performance of coatings. This instrument applied the pencil scratch method. It is a fast and economical way to determine the film hardness using the drawing lead core or the pencil core.



Description:

The Pencil Hardness Tester applies mechanical measurement. Keep three point touch the coating (two wheel, a pencil core), and a 45 degree angle between pencil and test surface. Push the instrument sliding, pencil draws the corresponding track in the coating. In the change of different pencil marks, the hardness value of the film can be determined.Paint Testing Equipment



Specification:

Load Weight 1000g /750g /500g
Measurement Angle 45°(Between Pencil and Measured Surface)
Three Touch Points Two Wheels, A Pencil Core
Scratch Speed About 1 mm/s
Standard Configuration Pencil Hardness Tester
1000g Weight
750g Weight
500g Weight
Pencils (6B-6H)
Eraser
Knife
Horizontal Pad Block
Sandpape

Load 500g 1000g Coating Hardness Tester  Pencil Hardness Tester For Paint 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.Paint Testing Equipment

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.Paint Testing Equipment

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
