220V Paint Testing Equipment GB9270-88 Paint Film Reflectance Tester

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-RT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name:: Paint Film Reflectance Tester Standard: ISO3906-1980(E)、GB/T13452.3-92、GB9270-88、GB5211.17-88
Warranty: 1 Year Input Power: 220V ± 10%, 50Hz
Measuring Range: 0 ~ 100 Repeatability: 0.3%
High Light:

Paint Testing Equipment GB9270-88

,

220V Paint Testing Equipment

Product Description

Paint Film Reflectance Tester Paint Testing Equipment



Standard:

ISO3906-1980(E),GB/T13452.3-92,GB9270-88,GB5211.17-88



Usage method::

1. Connect the probe to the electric control box, connect the power supply at the same time, and preheat the machine for 10-15 minutes. At this time, it is better to put the probe on the black standard plate.



2. Zero calibration: place the probe on the white standard plate, adjust the zero calibration knob on the host, so that the host digital display is 000.0, and the allowable change is ± 0.1



3. Calibration standard value: put the probe on the white standard plate, adjust the calibration knob of the host to make the value displayed by the host consistent with the calibration of the white standard plate. The allowable variation ± 0.1 shall be adjusted repeatedly once (zero calibration and calibration).



4. Measuring RB value: move the probe to the black working ceramic plate with the sample, and the value displayed on the display is the RB value.



5. Measuring RW value: move the probe to the white working ceramic plate with the sample, and the value displayed on the display is the RW value.



6. Calculate the contrast ratio (coverage ratio) = Rb / RW × 100%



Description:

The reflectance tester produced by our company is a special instrument developed for the chemical industry such as coating, pigment and ink to implement international and national standards. It can be used to measure the covering power of paint film. The instrument is composed of a probe, a main body, a standard plate (one black and white), and a working ceramic plate (two black and white).

The probe adopts the principle of 0 ° irradiation and diffuse reflection reception. When the reflected light of the sample acts on the surface of the silicon photocell, the electrical signal is input to the DC amplifier for amplification and reading display (see the optical circuit schematic diagram and instrument block diagram for details).Paint Testing Equipment



Specification:

Measuring range 0 ~ 100
Repeatability 0.3%
The display data is proportional to the reflected light intensity
The optical sensitivity of the instrument is approximately equal to the product of SC and y
Ambient temperature 20 ° ± 5 °
relative humidity < 85%
Input power 220V ± 10%, 50Hz
