NDJ-5S Rotary Viscometer Digital Drilling Fluids Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: NDJ-5S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Drilling Fluids Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Rotary Viscometer Digital NDJ-5S Warranty: 1 Year
Display Accuracy: 0.01Mpa. S Net Weight: 2kg (excluding Base)
Overall Dimension: 95 * 130 * 155 (excluding Base) Application: Drilling Fluids Testing Equipment

Product Description

NDJ-5S Rotary Viscometer Digital Drilling Fluids Testing Equipment



Description:

The Drilling Fluids Testing Equipment NDJ-5S digital display viscometer adopts a stepping motor and a driver, and operates smoothly according to the program setting. The motor drives the rotor to rotate at a constant speed through the torque sensor. When the rotor is subjected to viscous resistance in the measured liquid, the force is fed back to the torque sensor, and the viscosity data of the measured liquid can be displayed on the liquid crystal screen after corresponding internal processing and calculation.

This series of instruments has the advantages of convenient operation, intuitive reading, rich display content, stable rotation speed, anti-interference performance, wide working voltage [100 ~ 240V (50 / 60Hz)]



Specification:

Measuring range 1MPa When s - 100000mpa. S is lower than 15CP, No. 0 rotor shall be selected for test
Display accuracy 0.01Mpa. S
Measurement accuracy 5S ± 1% (full scale) 9s: ± 0.5% (full scale)
Rotor specification four rotors 1, 2, 3 and 4 (rotor 0 is optional)
Speed 6, 12, 30, 60 rpm / min
Overall dimension 95 * 130 * 155 (excluding base)
Net weight 2kg (excluding base)
Drilling Fluids Testing Equipment

NDJ-5S Rotary Viscometer Digital Drilling Fluids Testing Equipment 0



About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
