Digital Brookfield Viscometer Drilling Fluids Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: MK-BSND2\ MK-BSND4\ MK-BSND16
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Drilling Fluids Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Brookfield Viscometer Digital Rotor: Standard
Display Mode: LCD Display Test Error: ± 2% (Newtonian Liquid)
Repetition Error: ± 1% (Newtonian Liquid) Application: Drilling Fluids Testing Equipment

Product Description

Digital Brookfield Viscometer Drilling Fluids Testing Equipment



Description:

Brinell rotary viscometer (high temperature viscometer) adopts a coaxial center structure and uses a small amount of sample adapter. The sample amount required for each measurement is very small, and the temperature control is rapid and accurate. Full scale and linearity of each gear are all calibrated through PC interface and standard samples with different viscosities to ensure high accuracy and repeatability of the instrument. Wide measuring range, suitable for testing different materialsDigital Brookfield Viscometer Drilling Fluids Testing Equipment



Specification:

Display mode MK-BSND2 K-BSND4 | MK-BSND16
Display mode LCD display
Speed (R / min) 0.5/1/2/2.5/4/5/10/15/20/25/3 / / 5 / / / / / / / 118 revolutions
Measurement range (MPa. S)

500000-2000000

21 rotor: 500000-100000

27 rotor: 2.5-500000

28 rotor: 5-1 million

29 rotor: 10-2 million



1-4 million

21 rotor: 1-200000

27 rotor: 5-1 million

28 rotor: 10-2 million

Rotor 29: 20-4 million



4-16 million

21 rotor: 4-800000

27 rotor: 20-4 million

28 rotor: 40-8 million

29 rotor: 80-16 million



Sample quantity

Rotor 21: 7.8ml

27 rotor: 11.3ml

28 rotor: 12.6ml

29 rotor: 11.5ml



Test error ± 2% (Newtonian liquid)
Repetition error ± 1% (Newtonian liquid)
Temperature control accuracy 0.1 ℃
Temperaturecontrol range room temperature plus 10 ℃ - 250 (300 optional)
Print interface Yes

Digital Brookfield Viscometer Drilling Fluids Testing Equipment 0
