Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | NF-2 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Drilling Fluids Testing Equipment Standard export wooden box |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Adhesion Coefficient Tester Pneumatic Pressurization | Diameter Of Adhesive Disk: | φ 50.7 Mm |
---|---|---|---|
Working Pressure: | 3.5Mpa | Filter Area: | 22.6cm ² |
Maximum Pressure Resistance Of Drilling Fluid Cup: | 5MPa | Application: | Drilling Fluids Testing Equipment |
Product Description
Adhesion coefficient tester Pneumatic pressurization Drilling Fluids Testing Equipment
Description:
Drilling Fluids Testing Equipment NF-2 adhesion coefficient measuring instrument is a kind of analog test and analysis instrument, designed according to API standard. An adhesion disk is installed in the sealed mud cup. The adhesion disk is moved downward in the mud cup by the manual pressure rod. The torque wrench drives the adhesion disk to rotate on the surface of the mud cake. According to certain test procedures, the value is read by the torque wrench, and the adhesion coefficient of the mud cake is calculated through a series of formulas.
The adhesion coefficient tester is mainly used to monitor the friction coefficient between the drilling tool and the drilling fluid in the deep well, so as to treat the drilling fluid in time, improve its lubrication performance, prevent the occurrence of sticking accidents, and provide accurate and reliable data for ensuring fast and safe drilling. It has the characteristics of compact structure, high testing accuracy and convenient operation. It is used in various oil fields, scientific research institutes, laboratories and other departments.
Specification:
Diameter of adhesive disk | φ 50.7 mm |
Working pressure | 3.5Mpa |
Maximum pressure resistance of drilling fluid cup | 5MPa |
Filter area | 22.6cm ² |
The rated pressure of gas source nitrogen and carbon dioxide (without oil, water and other impurities) (oxygen is strictly prohibited) shall be greater than 5MPa | |
Drilling Fluids Testing Equipment |
