Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | ZS-20H |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Cement Testing Equipment Standard export wooden box |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Automatic Jolting Apparatus Cement Testing Equipment | Standard: | EN 196-1 EN ISO 679 |
---|---|---|---|
Warranty: | 1 Year | Total Weight Of Vibrating Part: | 20kg ± 0.5kg |
Amplitude (falling Distance): | 15mm ± 0.3mm | Weight: | 72kg |
High Light: | EN 196-1 Cement Testing Machine,EN ISO 679 Jolting Apparatus |
Product Description
Automatic Jolting Apparatus Cement Testing Equipment
Standard:
EN 196-1 EN ISO 679
Description:
ZS-20h cement mortar vibrating table is designed and manufactured according to the latest standard JC / T681 (2022 standard) and cement mortar strength test method (1S0 method) GB / t17671-2021. It is a cement mortar vibrating table. The product uses a color liquid screen to display the vibration times and control the jumping frequency. At the same time, it adopts a sound insulation design. During the vibration molding of the sample, the noise generated in the operation is greatly reduced. It is applicable to the preparation of samples used for cement strength inspection.Cement Testing Equipment.
Specification:
1. Total weight of vibrating part: 20kg ± 0.5kg |
2. Amplitude (falling distance): 15mm ± 0.3mm |
3. Vibration frequency: 60 times / 60 seconds ± 2 seconds |
4. Motor speed: 60 rpm |
5. Motor power: 70W, voltage: AC220V |
6. Distance from the center of the table to the center of the arm shaft: 800 ± 1mm |
7 total weight of two arms: 2.25kg + 0.25kg |
Horizontal distance from the center of 8 platen to the roller and cam axis: 100mm ± 1mm |
9. The working surface of the stopper is parallel to the platen and the two rods. The spherical radius of the working surface of the boss: r = 75mm ± 1mm |
10. Boundary dimension: 1170 * 420 * 415mm |
11. Weight: 72kg |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
