Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | FA type |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 |
Price: | Negotiable |
Packaging Details: | Drilling Fluids Testing Equipment Standard export wooden box |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Visible Sand Bed Non Permeable Filter | Effective Filtration Area: | 18cm2 |
---|---|---|---|
Working Pressure: | 0.69mpa | Sand Filter Injection Volume: | 350cm3 |
Drilling Fluid Injection Volume: | 500cm3 | Application: | Drilling Fluids Testing Equipment |
Product Description
Visible Sand Bed Non Permeable Filter Drilling Fluids Testing Equipment
Description:
The non permeable water loss instrument is to pour 300CM3 of 20 mesh to 40 mesh sand into the cylindrical perspective drilling fluid cup on the filter screen without filter paper, then pour 500cm3 of drilling fluid, tighten the cup cover, connect the air source, adjust the pressure to 0.69mpa, open the air release valve, and the air source enters the drilling fluid cup. The measurement starts. The filter area of the instrument is 18 ± 0.60cm2. The pressure is provided by the gas passing through the regulator. Observe the penetration of drilling fluid through the cup. It is widely used for drilling fluid analysis and determination in major oil fields, geological exploration and laboratories.Visible Sand Bed Non Permeable Filter Drilling Fluids Testing Equipment
Specification:
effective filtration area | 18cm² |
working pressure | 0.69mpa |
sand filter injection volume | 350cm³ |
drilling fluid injection volume | 500cm³ |
overall dimension | 400x250x1100mm |
Drilling Fluids Testing Equipment |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
