Stainless Steel Marsh Funnel Viscometer Drilling Fluids Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: MLN-4A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Drilling Fluids Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Marsh Funnel Viscometer Stainless Steel Warranty: 1 Year
Standard Measuring Cup: 946ml Volume Below The Filter Screen: 1500ml
The Mesh Diameter Is (1.6mm): 12 Mesh Application: Drilling Fluids Testing Equipment

Product Description

Stainless Steel Marsh Funnel Viscometer Drilling Fluids Testing Equipment



Structure:

It consists of a cone-shaped Marsh Funnel, a 12 mesh filter screen, a 946ml measuring cup and a 2000ml measuring cup.





Description:

The marsh funnel viscometer is made of high-quality stainless steel. It is a simple daily field used to measure the relative viscosity of mud (compared with water). It has simple structure, convenient operation and reflects the effective viscosity under certain conditions. The higher the funnel viscosity (seconds), the higher the apparent viscosity of the mud.Drilling Fluids Testing Equipment

Generally, mud flows out in laminar flow or structural state, which can reasonably reflect the changes of mud viscosity and consistency.





Specification:

Mahalanobis funnel: the diameter of the upper mouth of the cone is 152mm, the diameter of the lower mouth of the cone and the diameter of the guide pipe are 4.76mm and 50.8mm long. The length of cone is 305mm and the total length of funnel is 356mm.
The mesh diameter is (1.6mm) 12 mesh
Volume below the filter screen: 1500ml
Standard measuring cup 946ml
Drilling Fluids Testing Equipment

Stainless Steel Marsh Funnel Viscometer Drilling Fluids Testing Equipment 0

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
